Product Details:
|
| Thickness: | 0.5-3.0mm | Surface: | 2D 2B |
|---|---|---|---|
| Width: | 1220mm 1250mm 1500mm | Length: | 2438mm 2500mm 3000mm 6000mm |
| High Light: | stainless steel panels,stainless steel plate |
||
AISI 409L Stainless Steel Sheet Metal SUH409L Inox Sheet 409L Stainless Steel Composition
exhaust pipe used 409 409L SUH409L stainless steel sheet / plate / coil 3.0mm
Product Details:
| Product name | exhaust pipe used 409 409L SUH409L stainless steel sheet / plate / coil 0.5-3.0mm |
| Grade | 409L SUH409L |
| Standard | GB, JIS, ASTM, AISI |
| Surface | 2D/2B |
| Thickness | 0.5~10mm |
| Width | 1000~2500mm |
| Usage | 1.Widely used in the areas such as stainless steel fasteners,chains.kitchen and sanitarywares, furniture handles,handrail,electroplating and electrolyzing pendants, food, electro, petroleum, construction and decoration,etc. |
| 2.electronic products parts,medical appliances,springs,bus inside and outside packing and building, street lamp posts, etc.decoration materials and outdoor publicity billboard.used for the products which have the anti-stress corrosion requirement.electron products,table-wares, bolts, nuts, screen mesh, combustor and so on. | |
| Condition of delivery | Austenite in solution, ferrite in anneal or in accordance with client's detailed requirement |
| MOQ | 1 Metric ton |
| Price terms | CIF FOB CFR |
| Payment terms | L/C T/T |
| Supply ability | 500 Metric tons per day |
| Delivery Detail | 7-30 days,according to the quantity. |
| Packaging Detail | Full wrap by plastic packing-cloth |
Mirror fini
Fe, <0.08% C, 10.5-11.75% Cr, <0.5% Ni, <1.0% Mn, <1.0% Si, <0.045% P, <0.03% S, 6x%C-0.75% Ti
Grade 409 stainless steel is a Ferritic steel that offers good mechanical properties and high-temperature corrosion resistance. It is commonly considered as a chromium stainless steel, with applications in exhaust systems of automobiles and applications that demand weldability.
Grade 409 steels are also available in highly stabilized forms, such as grades S40930, S40920 and S40910. The stability of these grades is provided by the presence of niobium, titanium, or both, in the composition of steels.
The properties given below relate to annealed tubing of ASTM A268. The specified properties may not be similar to other products such as bar and coil.
The typical chemical compositional ranges of grade 409 stainless steels are given below:
Table 1 - Composition ranges of grade 409 stainless steels
| Grade | C | Mn | Si | P | S | Cr | Ni | Ti | |
| 409 |
min. max. |
- 0.08 |
- 1.00 |
- 1.00 |
- 0.045 |
- 0.045 |
10.5 11.75 |
- 0.5 |
6x C 0.75 |
The table below provides the mechanical properties of grade 409 stainless steels:
Table 2 - Mechanical properties of grade 409 stainless steels
| Grade | Tensile Strength (MPa) min | Yield Strength 0.2% Proof (MPa) min | Elongation (% in 50mm) min | Hardness | |
| Rockwell B (HR B) max | Brinell (HB) max | ||||
| 409 | 450 | 240 | 25 | 75 | 131 |
The physical properties of annealed grade 409 stainless steels are tabulated below:
Table 3 - Physical properties of annealed grade 409 stainless steels
| Grade | Density (kg/m3) | Elastic Modulus (GPa) | Mean Coefficient of Thermal Expansion (μm/m/°C) | Thermal Conductivity (W/m.K) | Specific Heat 0-100°C (J/kg.K) | Electrical Resistivity (nΩ.m) | |||
| 0-100°C | 0-315°C | 0-538°C | at 100°C | at 500°C | |||||
| 409 | 7800 | 200 | 11.0 | 11.7 | 12.4 | 25.8 | 27.5 | 460 | 600 |
Table 4 provides approximate grade comparisons of 409 stainless steels:
Table 4 - Grade specifications for 409 grade stainless steel
| Grade | UNS No | Old British | Euronorm | Swedish SS | Japanese JIS | ||
| BS | En | No | Name | ||||
| 409 | S40900 | 409S19 | - | 1.4512 | X6CrTi12 | - | SUH 409 |
sh goldcolor coated stainless steel bla
ck
