SS400 A36 Structural Steel Bars Bright Cold Drawn C45 / CK45 / 1.0503

Large Image : SS400 A36 Structural Steel Bars Bright Cold Drawn C45 / CK45 / 1.0503

Product Details:

Place of Origin:	China
Brand Name:	Mittel
Certification:	SGS ISO MTC
Model Number:	SAE1045

Payment & Shipping Terms:

Minimum Order Quantity:	200KGS
Price:	1.12 USD/KG
Packaging Details:	Wooden Box
Delivery Time:	14 Days
Payment Terms:	L/C, T/T
Supply Ability:	80000KGS

Contact Now

SS400 A36 Structural Steel Bars Bright Cold Drawn C45 / CK45 / 1.0503

Description

Steel Grade:	SAE1045	Alloy Or Not:	Non-alloy
Technique:	Hot Rolled,Cold Drawn	Type:	Flat Bar
Standard:	ASTM,DIN,AISI	Shape:	Flat
Length:	1--12m	Delivery Condition:	Annealed
Highlight:	ss400 structural steel bars , c45 structural steel bars , cold drawn a36 steel bar

S235jrQ235 SS400 A36 Cold drawn Bright Carbon Steel Round Bar Structural Steel Bar

Product Name	Cold Drawn steel bar
Technique	Cold Drawn
Type	Low Carbon Steel, Medium Carbon Steel
Place of Origin	JIANGSU, China(mainland)
Grade	GB	DIN		JIS	ASTM/SAE/AISI	BS
	20#	C22/CK22		S20C	1020	IC22
	45#	C45/CK45/1.0503		S45C/S48C	1045	060A42/060A47
	Q235B	S235jr		SS400	A36	S235jr
	Q345B	SM490		S355JR	------	S355JR
Section Shape	Round, square, hexagonal, flat, deformed
Surface	Bright
Specifications	Round Bar		4mm-80mm
	Flat Bar		Length: 20-150mm
			Width: 3-80mm
	Square Bar		44mm-8080mm
	Hexagon bar		4-80mm
	Deformed		Special drawings
Length	2m, 4m, 5.8m, 6m or as required
delivery condition	cold drawn , anneal or not
Payment Terms	T/T, L/C
Package	Bundled, wooden box for export standard package
Price Terms	EXW, FOB, CIF,CFR
Delivery Time	Normally according to the order quantity
Container Size	20ft GP:5898mm(Length)x2352mm(Width)x2393mm(High) 40ft GP:12032mm(Length)x2352mm(Width)x2393mm(High) 40ft HC:12032mm(Length)x2352mm(Width)x2698mm(High)

45# Cold Drawn SAE 1045 Square Bar 4040 5050 60*60mm Chemical Composition

Chemical composition %:
C	Si	Mn	S	P	Cr	Ni	Cu
0.4-0.45	0.17-0.37	0.70-1.00	≤0.035	≤0.035	≤0.25	≤0.30	≤0.25

SAE 1045 Carbon Steel Flat Bar Mechanical Properties

mechanical properties:
Tensile strength σb (Mpa)	Yield strength σb (Mpa)	Elongation σb (%)	reduction of area ψ (%)	Hardness No heat treatment	Impacting Energy Akv (J)	Notched bar impact strength αkv (J/cm2)
min	min	min	min	max	min	min
540(55)	315(32)	20	45	217HB	63	78(8)

WE CAN OFFER PRODUTS LIKE THESE
Round Bar	Diameter3-800mm or as required
AngleBar	Size:32020mm-12100100mm as required
Square Bar	Size:44mm-100100mm as required
Flat Bar	TK:2-100 width:10-500mm as required
Hexagonal Bar	Size:2-100mm as required

Chemical Elements

GB	C	Si	Mn	S	P	Cr
20	o.17-0.23	0.17-0.37	0.35-0.65	Max0.035	Max 0.035	Max0.25
45	0.42-0.5	0.17-0.37	0.5-0.8	max 0.035	max 0.035	max 0.25
Q235b	0.12-0.22	max 0.3	0.3-0.65	max 0.05	max 0.045	max0.02
Q345b	Max 0.2	Max0.55	Max1.7	Max0.035	Max0.04	Max0.3
