DUPLEX WELDED 2507 Stainless Steel Welded Pipe, FULL FINISHED AND BRIGHT ANNEALED, SMOOTH ENDS, FREE OF BURRS

DUPLEX WELDED 2507 Stainless Steel Welded Pipe, FULL FINISHED AND BRIGHT ANNEALED, SMOOTH ENDS, FREE OF BURRS
DUPLEX WELDED 2507 Stainless Steel Welded Pipe, FULL FINISHED AND BRIGHT ANNEALED, SMOOTH ENDS, FREE OF BURRS DUPLEX WELDED 2507 Stainless Steel Welded Pipe, FULL FINISHED AND BRIGHT ANNEALED, SMOOTH ENDS, FREE OF BURRS DUPLEX WELDED 2507 Stainless Steel Welded Pipe, FULL FINISHED AND BRIGHT ANNEALED, SMOOTH ENDS, FREE OF BURRS

Large Image :  DUPLEX WELDED 2507 Stainless Steel Welded Pipe, FULL FINISHED AND BRIGHT ANNEALED, SMOOTH ENDS, FREE OF BURRS

Product Details:
Place of Origin: CHINA
Brand Name: TISCO,BAO STEEL
Certification: SGS,ISO
Model Number: 2507 S32750
Payment & Shipping Terms:
Minimum Order Quantity: 1 Ton
Price: 7500 USD/Ton
Packaging Details: Export packing
Delivery Time: 5-10 days according to the quantity
Payment Terms: T/T or L/C
Supply Ability: 5000 Tons every month

DUPLEX WELDED 2507 Stainless Steel Welded Pipe, FULL FINISHED AND BRIGHT ANNEALED, SMOOTH ENDS, FREE OF BURRS

Description
Length: 6-11meter OD: 10-325mm
Thickness: SCH10 - SCH 160 Technique: Welded
Steel Grade: Duplex Stainless Steel Welding Line Type: ERW
Standard: ASTM,AISI,DIN Application: Construction,Decoration,Industry
Shape: Round.square.Rectangle Surface: Annealing
Thickness: 0.5-25.4mm
High Light:

ss seamless pipes

,

astm stainless steel pipe

Standard: ASTM/ASME A/SA789, A/SA790, A/SA928, DIN17456/17458, EN10216-5. After negotiation, we can supply

pipe with customers'requirement.

Material Grade:

UNS EN DIN C % Cr% Ni% Mo% N% Other %
S31803 1.4462 X2CrNiMoN22-5-3 0.030max 21.0-23.0 4.5-6.5 2.5-3.5 0.08-0.20 /
S32205 1.4462 X2CrNiMoN22-5-3 0.030max 22.0-23.0 4.5-6.5 3.0-3.5 0.14-0.20 /
S32101 1.4162   0.040max 21.0-22.0 1.35-1.70 0.10-0.80 0.20-0.25 Cu 0.10-0.80
S32304     0.030max 21.5-24.5 3.0-5.5 0.05-0.60 0.15-0.20 Cu 0.05-0.60
S32750 1.4410 X2CrNiMoN25-7-4 0.030max 24.0-26.0 6.0-8.0 3.0-5.0 0.24-0.32 Cu 0.50max
S32760     0.050max 24.0-26.0 6.0-8.0 3.0-4.0 0.20-0.30 Cu 0.50-1.00





Mechanical Property:



UNS Tensile Strength
Min, Mpa
Yield Strength
Min, Mpa
Elongation in 2 in Or 50mm Min, % Hardness Max,
HRC
S31803 620 450 25 30
S32205 655 485 25 30
S32101 700 530 30 30
S32304 690 450 25 30
S32750 800 550 15 32
S32760 750 550 25 32



Size Range:



Stainless Steel Seamless Tube ASTM A789/A789M: OD: Φ12.7mm-Φ203mm; WT:0.5mm-6.35mm
Stainless Steel Welded Tube ASTM A789/A789M: OD: Φ12.7mm-Φ203mm; WT:0.5mm-4.0mm



Duplex Stainless Steel have a structure that contains both ferrite and austenite. Duplex alloys have higher strength and better stress corrosion cracking resistance than most austenitic alloys and greater toughness than ferritic alloys, especially at low temperatures. The corrosion resistance of duplex alloys depends primarily on their composition, especially the amount of chromium, molybdenum, and nitrogen they contain.





Standard: ASTM/ASME A/SA789, A/SA790, A/SA928, DIN17456/17458, EN10216-5. After negotiation, we can supply pipe with customers'requirement.

Material Grade:UNS S31803,S32205,S32101,S32304,S32750,S32760,1.4462,1.4410etc.

Size Range:



Stainless Steel Seamless Tube ASTM A789/A789M: OD: Φ12.7mm-Φ203mm; WT:0.5mm-6.35mm
Stainless Steel Seamless Pipe ASTM A790/A790M: OD: Φ6mm-Φ325mm; WT:0.5mm-30mm
Stainless Steel Welded Tube ASTM A789/A789M: OD: Φ12.7mm-Φ203mm; WT:0.5mm-4.0mm



Stainless Steel Welded Pipe

ASTM A790/A790M: OD: Φ10mm-Φ2000mm; WT:0.5mm-40mm

(OD≤630mm for single seam; OD>Φ630mm For circumferential seam)

ASTM A928/A928M: OD: Φ10mm-Φ406mm; WT:0.5mm-10mm.



Chemical Composition, %

Cr

Ni

Mo

C

N

Mn

24.0-26.0

6.0-8.0

3.0-5.0

0.030 Max

.24-.32

1.20 Max

Si

Cu

P

S

Fe



0.80 Max

0.50 Max

0.035 Max

0.020 Max

Balance



In what applications is Duplex 2507 used?

  • Desalination Equipment
  • Chemical process pressure vessels, piping and heat exchangers
  • Marine Applications
  • Flue Gas Scrubbing Equipment
  • Pulp & Paper Mill Equipment
  • Offshore Oil production/technology
  • Oil and gas industry equipment

ASTM Specifications

Pipe Smls

Pipe Welded

Tube Smls

Tube Welded

Sheet/Plate

Bar

Flanges & Fittings

A790

A790

A789

A789

A240

A276

A182

Mechanical Properties
Specified Tensile Properties, Plate ASTM A240

Ultimate Tensile Strength, ksi Minimum

.2% Yield Strength, ksi Minimum

% Elongation Min.



116

80

15

310
