UNS S31703 Welding Stainless Steel Seamless Pipe Hot Rolled 317L

Stainless 317 L has a high tensile and creep strength at elevated temperatures. Due to its excellent corrosion resistance it has been used in handling many of the chemicals used by the chemical process industries.

Is Grade 317 Stainless Steel Worth the Cost Over 316 & 304?

With hundreds of different types of steel alloys on the market, it can be tough to find the perfect metal for your application. In many buying processes, the first consideration is the cost of the metal rather than the performance of the metal—which can be a serious mistake.

There are some cases where paying extra for a different, higher-performing alloy is necessary.

What Makes Grade 317 SS Different from 304 & 316 SS?

Grade 304, 316, and 317 stainless steel are all considered austenitic stainless steel alloys. These alloys all share some similar properties, such as high strength, corrosion resistance, and high concentrations of chromium and nickel.

What separates 316 and 317 SS from 304 SS is that these higher-numbered alloys have added molybdenum in their formulation—grade 316 has about 2-3% molybdenum, and grade 317 has more than 3% molybdenum.

This added molybdenum greatly improves the steel’s resistance to pitting from chlorides, which is why grade 316 SS is often used in the chemical processing and marine industries.

However, this added molybdenum content also influences the cost of these two alloys. Grade 317 SS is generally more expensive than grade 316 SS. 316 SS, in turn, is more expensive than grade 304 SS. The exact extra cost varies based on the market at the time.

When is 317 SS Worth the Extra Cost Over 316 SS?

For most strongly corrosive applications, grade 316 should be more than enough to resist frequent exposure.

However, 317 does achieve better resistance to some specific corrosives than 304 or 316. As noted by an ATI Metals publication, in a boiling test solution of 1% hydrochloric acid, the corrosion rate of 317 SS was 54.2 mils/year, while 316 SS corroded at a rate of 226 mils/year. 317 SS also significantly outperforms 316 SS in sulfuric acid and sodium hydroxide tests.

So, if your processes involve the use of very diluted (less than 3-4%) hydrochloric acid, mild concentration (10%) sulfuric acid, or sodium hydroxide (aka caustic soda), then grade 317 stainless steel might be worth the extra cost over 316 or 304 SS.

It’s important to note that hydrochloric acid in any concentration above 5% will quickly erode any austenitic stainless steel alloy with ease.

Also, in the previously-cited chemical corrosion tests, 317 performed worse against some corrosives than 316, such as phosphoric acid (0.72 mils/year vs 0.2 mils/year) and acetic acid (0.48 mils/year vs 0.12 mils/year).
