Product Details:
|
| Certification: | CE, ISO, BV, SGS | Stock: | Always In Good Stock |
|---|---|---|---|
| Product Name: | Stainless Steel Seamless Pipe & Tube | Outer Diameter: | DN10 - DN500 |
| Wall Thickness: | SCH5 - SCH160 | Standard: | AISI, ASTM, JIS, DIN, EN, GB |
| Color: | Natural Color | Quality: | Class 1 |
| Type: | Seamless | Main Grade: | 304 304L 304H 309S 310S 316L 316Ti 321 347 .etc |
| High Light: | corrugated ss Seamless Pipe,TP321 Stainless Steel Seamless Pipe,ss Seamless Pipe For Kitchenware |
||
ASTM A312 TP304 TP304L TP310S TP321 TP347 Stainless Steel Seamless Pipe / SS Pipe
More informations of our stainless steel pipe
| Products | Stainless Steel Pipe &Tube |
| Place of Origin | China |
| Model Number | 200 Series:201 202 |
| 300 Series:301 302 303 304 304L 309 309S 310 316 316L 321 904L | |
| 400 Series:410 420 430 440 | |
| Duplex stainless:2205 2507 | |
| Type | Flat/corrugated/checkered |
| Processing Service | Bending,Welding,Decoiling,Punching,Cutting, Moulding |
| Delivery Time | 3-10 days |
| Payment terms | 30%TT Advance+70% Balance against the copy of bill of loading |
| Sample | Sample Avaliable |
| Inspection | Accept Thrid Party Inspection |
| Port | Tianjin Shanghai Qingdao |
| Certification | ISO9001 |
| Packing | Standardsea worthy export packing or according to the customers' request. |
| Applications: | Kitchenware,home appliances,construction decoration,stairs,refrigerated container,burner parts,exhaust parts of auto |
| Container Size: | 20ft GP:5898mm(Length)x2352mm(Width)x2393mm(High)24-26CBM |
| 40ft GP:12032mm(Length)x2352mm(Width)x2393mm(High)54CBM | |
| 40ft HC:12032mm(Length)x2352mm(Width)x2698mm(High)68CBM |
stainless steel pipe inventory features both seamless and welded pipe that is cold finished, annealed and pickled in a range of diameters and stock lengths. Offered in both 304/304L and 316/316L alloys, our stainless steel pipe blends corrosion resistance with strength and is ideally suited for use in harsh conditions such as saltwater, chemical and acidic environments. Stainless pipe is popular for many applications, ranging from mining and manufacturing to the oil and gas and foodservice industries.
All of our stainless pipe inventory can be cut to your specifications. In addition, our stainless pipe processing services include drilling, welding and bending.
Stainless steel pipe dimension as per astm & weight
| Nominal | Outside Diameter | Sch 5S | Sch 10S | Sch-40S | Sch-80S | Sch-160S | Sch-XXS | |||||||
| mm | inch | mm | WT mm | Weight (Kg/mt) | WT mm | Weight (Kg/mt) | WT mm | Weight (Kg/mt) | WT mm | Weight (Kg/mt) | WT mm | Weight (Kg/mt) | WT mm | Weight (Kg/mt) |
| 3 | 1/8 | 10.3 | 1.24 | 0.276 | 1.24 | 0.28 | 1.73 | 0.37 | 2.41 | 0.47 | - | - | - | - |
| 6 | 1/4 | 13.7 | 1.24 | 0.390 | 1.65 | 0.49 | 2.24 | 0.631 | 3.02 | 0.80 | - | - | - | - |
| 10 | 3/8 | 17.1 | 1.24 | 0.490 | 1.65 | 0.63 | 2.31 | 0.845 | 3.20 | 1.10 | - | - | - | - |
| 15 | 1/2 | 21.3 | 1.65 | 0.800 | 2.11 | 1.00 | 2.77 | 1.27 | 3.75 | 1.62 | 4.75 | 1.94 | 7.47 | 2.55 |
| 20 | 3/4 | 26.7 | 1.65 | 1.03 | 2.11 | 1.28 | 2.87 | 1.68 | 3.91 | 2.20 | 5.54 | 2.89 | 7.82 | 3.63 |
| 25 | 1 | 33.4 | 1.65 | 1.30 | 2.77 | 2.09 | 3.38 | 2.50 | 4.55 | 3.24 | 6.35 | 4.24 | 9.09 | 5.45 |
| 32 | 1 1/4 | 42.2 | 1.65 | 1.65 | 2.77 | 2.70 | 3.56 | 3.38 | 4.85 | 4.47 | 6.35 | 5.61 | 9.70 | 7.77 |
| 40 | 1 1/2 | 48.3 | 1.65 | 1.91 | 2.77 | 3.11 | 3.68 | 4.05 | 5.08 | 5.41 | 7.14 | 7.25 | 10.16 | 9.54 |
| 50 | 2 | 60.3 | 1.65 | 2.40 | 2.77 | 3.93 | 3.91 | 5.44 | 5.54 | 7.48 | 8.74 | 11.1 | 11.07 | 13.44 |
| 65 | 2 1/2 | 73.0 | 2.11 | 3.69 | 3.05 | 5.26 | 5.16 | 8.63 | 7.01 | 11.4 | 9.53 | 14.9 | 14.2 | 20.39 |
| 80 | 3 | 88.9 | 2.11 | 4.51 | 3.05 | 6.45 | 5.49 | 11.30 | 7.62 | 15.2 | 11.1 | 21.3 | 15.24 | 27.65 |
| 100 | 4 | 114.3 | 2.11 | 5.84 | 3.05 | 8.36 | 6.02 | 16.07 | 8.56 | 22.3 | 13.49 | 33.54 | 17.12 | 41.03 |
| 125 | 5 | 141.3 | 2.77 | 9.47 | 3.40 | 11.57 | 6.55 | 21.8 | 9.53 | 31.97 | 15.88 | 49.11 | 19.05 | 57.43 |
| 150 | 6 | 168.3 | 2.77 | 11.32 | 3.40 | 13.84 | 7.11 | 28.3 | 10.97 | 42.7 | 18.2 | 67.56 | 21.95 | 79.22 |
| 200 | 8 | 219.1 | 2.77 | 14.79 | 3.76 | 19.96 | 8.18 | 42.6 | 12.7 | 64.6 | 23.0 | 111.2 | 22.23 | 107.8 |
| 250 | 10 | 273.1 | 3.40 | 22.63 | 4.19 | 27.78 | 9.27 | 60.5 | 12.7 | 96.0 | 28.6 | 172.4 | 25.40 | 155.15 |
| 300 | 12 | 323.9 | 3.96 | 31.25 | 4.57 | 36.00 | 9.52 | 73.88 | 12.7 | 132.0 | 33.32 | 238.76 | 25.40 | 186.97 |
| 350 | 14 | 355.6 | 3.96 | 34.36 | 4.78 | 41.3 | 11.13 | 94.59 | 19.05 | 158.08 | 35.71 | 281.70 | - | - |
| 400 | 16 | 406.4 | 4.19 | 41.56 | 4.78 | 47.29 | 12.7 | 123.30 | 21.41 | 203.33 | 40.46 | 365.11 | - | - |
| 450 | 18 | 457.2 | 4.19 | 46.80 | 4.78 | 53.42 | 14.27 | 155.80 | 23.8 | 254.36 | 45.71 | 466.40 | - | - |
| 500 | 20 | 508.0 | 4.78 | 59.25 | 5.54 | 68.71 | 15.09 | 183.42 | 26.19 | 311.2 | 49.99 | 564.68 | - | - |
| 600 | 24 | 609.6 | 5.54 | 82.47 | 6.35 | 94.45 | 17.48 | 255.41 | 30.96 | 442.08 | 59.54 | 808.22 | - | - |
