Product Details:
|
| Commodity: | Stainless Steel Strips & Coils | Thickness: | 0.01mm-8.0mm |
|---|---|---|---|
| Width: | 6.0 - 1219mm Customs As Request | Standard: | JIS, AISI, ASTM, GB, DIN, EN |
| Type: | Coil & Strip | Brand Name: | Baosteel, Tisco, Lisco, Posco |
| Surface Finish: | NO.1, 2B , BA , NO.4, 8k, HL | Inner Package: | Waterproof Paper |
| Outer Package: | Ooden Box, Woven Bag With Bundles | Application: | Construction, Machine Building |
| High Light: | 0.01mm cold rolled stainless steel strip,Hot Rolled cold rolled stainless steel strip,301 201 stainless steel strip |
||
Specification of our stainless steel strips
| Type | Stainless steel strip |
| Size/thinckness | 0.01mm-8.0mm |
| Widthness | 6 - 1219mm |
| Surface | 2B BA NO.4 NO.1 HL 8K.etc |
| Brand name | TISCO,BAOSTEEL , LISCO , BXSS POSCO |
| Standard | EN 10088-2 / ASTM A240 GB JIS G4305 |
| Coil width tolerance | within 0.2mm |
| Packing |
# shape wooden frame and waterproof paper |
| MOQ | within 500 kgs |
| Delivery time | 5 - 12 days based on the quantity |
Stainless steel strip is simply an extension of an ultra thin stainless steel plate. A narrow and long steel plate produced mainly in order to meet the needs of industrial production of various metals or mechanical products in different industrial sectors.Actually,stainless steel is produced by stainless steel coil.Usually use the slitting machine to process it into strip,with the same usage with stainless steel coil.
|
Technical |
Grade |
Thickness |
Width |
Finish |
Origin |
| Cold rolled |
201/202/304/304L/321/316L |
0.02mm-3.00mm | 2-600mm |
2B/BA/No.4/HL/ |
TISCO/ZPSS/JISCO/LISCO etc |
| Hot rolled |
201/202/304/304L/321/316L |
3.0mm-12.00mm | 5-600mm | No.1 | TISCO/ZPSS/JISCO/LISCO etc |
|
Grade |
Temper |
HV |
YS(Mpa) |
TS(Mpa) |
EL(%) |
| 304 | ANN | ≤200 | ≥205 | ≥520 | ≥40 |
| 1/2H | 250-310 | ≥470 | ≥780 | ≥6 | |
| 3/4H | 310-370 | ≥665 | ≥930 | ≥3 | |
| FH | ≥370 | ≥880 | ≥1130 | ---- | |
| 301 | ANN | ≤200 | ≥205 | ≥520 | ≥40 |
| 1/2H | 310-370 | ≥510 | ≥930 | ≥10 | |
| 3/4H | 370-430 | ≥745 | ≥1130 | ≥5 | |
| FH | 430-490 | ≥1030 | ≥1320 | ≥3 | |
| EH | 490-530 | ≥1275 | ≥1570 | ---- |
| HLD | HRC | HRB | HV | HB(1) | HB(2) | HSD |
| 400 | 75 | 131 | 142 | |||
| 410 | 77.5 | 138 | 150 | |||
| 416 | 78.9 | 142 | 155 | |||
| 430 | 81.9 | 152 | 147 | 165 | ||
| 440 | 84 | 160 | 154 | 172 | ||
| 450 | 85.9 | 168 | 162 | 179 | ||
| 460 | 87.7 | 176 | 170 | 187 | 26.4 | |
| 470 | 89.5 | 185 | 178 | 194 | 27.9 | |
| 480 | 91.3 | 194 | 187 | 202 | 29.4 | |
| 490 | 93.1 | 203 | 196 | 209 | 30.9 | |
| 500 | 95 | 213 | 205 | 217 | 32.2 | |
| 510 | 19.8 | 97 | 223 | 215 | 225 | 33.6 |
| 520 | 21.7 | 99.2 | 233 | 225 | 234 | 35 |
| 530 | 23.5 | 244 | 236 | 242 | 36.4 | |
| 540 | 25.2 | 255 | 246 | 252 | 37.9 | |
| 550 | 26.8 | 266 | 258 | 261 | 39.3 | |
| 560 | 28.4 | 278 | 269 | 272 | 40.8 | |
| 570 | 30 | 290 | 281 | 282 | 42.3 | |
| 580 | 31.5 | 302 | 293 | 294 | 43.8 | |
| 590 | 33 | 315 | 306 | 308 | 45.4 | |
| 600 | 34.5 | 328 | 319 | 320 | 46.9 | |
| 610 | 35.9 | 341 | 332 | 333 | 48.5 | |
| 620 | 37.4 | 355 | 346 | 346 | 50.1 | |
| 630 | 38.7 | 369 | 360 | 360 | 51.7 | |
| 640 | 40.1 | 383 | 374 | 374 | 53.3 | |
| ------ | ------ | ------ | ----- | ------ | ------ | ----- |
| 880 | 67.8 | 938 | 99 | |||
| 890 | 68.5 | 976 |
Usually,stainless steel strip is widely used in our daily life.A narrow and long steel plate produced mainly in order to meet the needs of industrial production of various metals or mechanical products in different industrial sectors.With same usage as stainless steel coil,the only differences between this two material is thr type.
1)Stainless steel strip is an extension of ultra thin stainless steel plate,so it’s widely used in industrial seet.
2)Because stainless steel strip thickness is thinner that other thickness,so it’s widely used to make Spring.(Like 301 grade material)
3)High temperature resistance, corrosion resistance, resistance to deformation and so on. So it is widely used in industry and construction .
4)Cold rolled steel strips have also been widely used in tractors, automobiles ,Aviation, aerospace, etc.
Usually wooden pallet with anti-water paper,then fixed with iron sheet.This packaging is very worthy for sea freight.Or according to customers requirements.
