DIN S45c Q235b St70 Square Steel Rod Cold Drawn Bar

DIN S45c Q235b St70 Square Steel Rod Cold Drawn Bar
DIN S45c Q235b St70 Square Steel Rod Cold Drawn Bar DIN S45c Q235b St70 Square Steel Rod Cold Drawn Bar DIN S45c Q235b St70 Square Steel Rod Cold Drawn Bar

Large Image :  DIN S45c Q235b St70 Square Steel Rod Cold Drawn Bar

Product Details:
Place of Origin: China
Brand Name: Mittel
Certification: SGS ISO MTC
Model Number: SAE1045
Payment & Shipping Terms:
Minimum Order Quantity: 200KGS
Price: 1.12 USD/KG
Packaging Details: Wooden Box
Delivery Time: 14 Days
Payment Terms: L/C, T/T
Supply Ability: 80000KGS

DIN S45c Q235b St70 Square Steel Rod Cold Drawn Bar

Description
Steel Grade: Ss400 A36 S45c Sae1045 42CrMo Alloy Or Not: Non-alloy
Technique: Hot Rolled,Cold Drawn Type: Flat Bar
Standard: ASTM,DIN,AISI Shape: Flat
Length: 1--12m Delivery Condition: Annealed
High Light:

st70 square steel rod

,

din square steel rod

,

s45c cold drawn bar

Useful information of SAE 1045 Carbon Steel Flat Bar

SAE 1045 Carbon Steel Flat Bar Chemical Composition

Chemical composition %:
C Si Mn S P Cr Ni Cu
0.4-0.45 0.17-0.37 0.70-1.00 ≤0.035 ≤0.035 ≤0.25 ≤0.30 ≤0.25

SAE 1045 Carbon Steel Flat Bar Mechanical Properties

mechanical properties:
Tensile strength σb
(Mpa)
Yield strength σb
(Mpa)
Elongation σb
(%)
reduction of area
ψ (%)
Hardness
No heat treatment
Impacting Energy Akv (J) Notched bar impact strength
αkv (J/cm2)
min min min min max min min
540(55) 315(32) 20 45 217HB 63 78(8)

1045 steel bar is a medium tensile low hardenability carbon steel generally supplied in the black hot rolled or occasionally in the normalized condition.

Get PriceSend E-mail

1045 steel bar is a medium tensile low hardenability carbon steel generally supplied in the black hot rolled or occasionally in the normalized condition.

Similar Grades

Standard Grade Chemical composition (%)
C Si Mn P S
GB 45 0.42-0.50 0.17-0.37 0.50-0.80 ≤0.035 ≤0.035
ASTM 1045 0.43-0.50 0.10-0.20 0.60-0.90 ≤0.040 ≤0.050
JIS S45C 0.42-0.48 0.15-0.35 0.60-0.90 ≤0.030 ≤0.030
DIN C45/1.0503 0.42-0.50 ≤0.40 0.50-0.80 ≤0.045 ≤0.045

Available Size

Cold drawn square bar: 8*8MM-100*100MM

Available Heat Treatment

Annealing/Normalizing/Hardening/Tempering/Quenching

Characteristics

1. Medium carbon steel

2. Better mechanical property advantages over 1018

3. Good heat treatment response

4. Fair welding characteristics

Application

Axles, bolts, connecting rods, hydraulic clamps and rams, pins, rolls, studs, shafts, spindles, etc.

Delivery Condition

Cold drawn

DIN S45c Q235b St70 Square Steel Rod Cold Drawn Bar 0DIN S45c Q235b St70 Square Steel Rod Cold Drawn Bar 1DIN S45c Q235b St70 Square Steel Rod Cold Drawn Bar 2
