HASTELLOY C4 DIN 2.4610 HASTELLOY ALLOY STRUCTURAL STEEL PLATE

HASTELLOY C4  DIN 2.4610 HASTELLOY ALLOY STRUCTURAL STEEL PLATE
HASTELLOY C4  DIN 2.4610 HASTELLOY ALLOY STRUCTURAL STEEL PLATE
HASTELLOY C4  DIN 2.4610 HASTELLOY ALLOY STRUCTURAL STEEL PLATE HASTELLOY C4  DIN 2.4610 HASTELLOY ALLOY STRUCTURAL STEEL PLATE HASTELLOY C4  DIN 2.4610 HASTELLOY ALLOY STRUCTURAL STEEL PLATE HASTELLOY C4  DIN 2.4610 HASTELLOY ALLOY STRUCTURAL STEEL PLATE

Large Image :  HASTELLOY C4 DIN 2.4610 HASTELLOY ALLOY STRUCTURAL STEEL PLATE

Product Details:
Place of Origin: China
Brand Name: Mittel
Certification: SGS ISO MTC
Model Number: HASTELLOY C4
Payment & Shipping Terms:
Minimum Order Quantity: 100KGS
Price: 35 USD/KG
Packaging Details: Wooden Pallet BOX
Delivery Time: 7 Working Days
Payment Terms: L/C, T/T
Supply Ability: 80000KGS

HASTELLOY C4 DIN 2.4610 HASTELLOY ALLOY STRUCTURAL STEEL PLATE

Description
Grade: Nickel Base Alloy Application: Industry,construction,deep-drawn,used In Chemical
Type: Nickel Plate Elongation (≥ %): 40%
Resistance (μω.m): 1.5,Stable,DIN,UNS Ni (min): 99.5%,Balance,Standard
Powder Or Not: Not Powder Ultimate Strength (≥ Mpa): DIN,Standard
Standard: ASTM,DIN Material: Hastelloy C22 C4 C276
Thickness: 1mm~30mm

HASTELLOY C4 DIN 2.4610 HASTELLOY ALLOY STRUCTURAL STEEL PLATE



Hastelloy C4 Coils is a nickel-chromium-molybdenum alloy with outstanding high-temperature stability as evidenced by high ductility and corrosion resistance even after aging in the 1200 to 1900 Degree F (649 to 1038 Degree C) range. In Inconel C4 Plates, the tungsten was totally omitted and the iron content was reduced to approximately 1%. The alloy also contains approximately 0.3% Ti. Haynes C4 Plates is used to manufacture chemical process equipment, especially for process use at high temperatures where stainless steels do not have adequate strength and/or corrosion resistance. Nickel C4 Plates resists the formation of grain-boundary precipitates in the weld heat-affected zone, thus making it suitable for most chemical process applications in the as-welded condition. Buy Alloy C4 Plates at reasonable price from us.

Specifications ASTM B575 / ASME SB575
Standard ASTM, ASME and API
Specialize Shim Sheet, Perforated Sheet, B. Q. Profile.
Size 0.5 MM TO 200 MM THICK IN 1000 MM TO 2500 MM WIDTH & 2500 MM TO 12500 MM LENGTH
Form Coils, Foils, Rolls, Plain Sheet, Shim Sheet, Perforated Sheet, Chequered Plate, Strip, Flats, Blank (Circle), Ring (Flange)
Finish Hot rolled plate (HR), Cold rolled sheet (CR), 2B, 2D, BA NO(8), SATIN (Met with Plastic Coated)
Hardness Soft, Hard, Half Hard, Quarter Hard, Spring Hard etc.
Grade Hastelloy C4 (UNS N06455)

Hastelloy C4 Plates Equivalent Grades

STANDARD WERKSTOFF NR. UNS
Hastelloy C4 2.4610 N06455

C4 Hastelloy Plates Chemical Composition :

Grade Ni Cr Mo Fe C Mn Si Co Ti S P
Hastelloy C4 Bal 14.5-17.5 14.0-17.0 Max 3.0 Max 0.009 Max 1.0 Max 0.05 Max 2.0 Max 0.7 Max 0.010 Max 0.025

ASTM B575 Hastelloy C4 Plates Mechanical Properties:

Grade Tensile Strength Yield Strength RP0.2% Elongation A5% Mean Coefficient of Thermal Expansion
Hastelloy C4 690 N/mm² 1335°C-1380°C 275 N/mm² 40%

Hastelloy C4 Plates Physical Properties:

Grade Density Melting Point Electrical Resistivity Mean Coefficient of Thermal Expansion Thermal Conductivity Specific Heat
Hastelloy C4 8.6g/cm3 1335°C-1380°C 1.24 μΩ•m 10.9(100°C) a/10-6°C-1 10.1(100°C) λ/(W/m•°C) 408 J/kg•°C

Types Of Hastelloy C4 Plates

Hastelloy C4 Plates Hastelloy C4 Plates
C4 Alloy Plates Hastelloy C4 Plate
Super Nickel alloy Hastelloy C4 Plate Hastelloy UNS N06455 Bright plate
DIN 2.4610 Hastelloy Structural Steel Plates Prime Hastelloy C4 Alloy Steel Plate manufacturer
Hastelloy Alloy C4 Cold Rolled Sheet Corrosion Resistance Super Alloy Hastelloy C4 Plate
UNS N06455 Hastelloy Alloy Sheets ASME SB 575 Hastelloy C4 Sheets
ASTM B575 Hastelloy C4 Sheet Alloy C4 Sheets Stockiest
High quality C4 Hastelloy Alloy Plate Hastelloy C4 Plates Suppliers
Hastelloy Alloy C4 Plates Dealer C4 Hastelloy B575 Plates Exporter
Alloy C4 Plates Stockholder Hastelloy Alloy SB 575 Plates Distributor
Application Of Hastelloy Industries


Application of Hastelloy in Petrochemical Industries

Petrochemical Industries



Application of Hastelloy in Marine Industries

Marine Industries



Application of Hastelloy in Food Processing Industries

Food Processing Industries



Hastelloy Application in Oil & Gas Industries

Oil & Gas Industries



Packing Of Hastelloy Materials

HASTELLOY C4  DIN 2.4610 HASTELLOY ALLOY STRUCTURAL STEEL PLATE 4
