Product Details:
|
| Material: | Metal,stainless Steel | Shape: | Flat |
|---|---|---|---|
| Application: | Landscaping,Indoor And Outdoor Garden Decoration | Usage: | Garden Decoration,flower And Plants Planting,outdoor,office |
| Thickness: | 1-3mm,1.0mm Or Customized | Width: | 100-2000mm |
| High Light: | 3mm alloy 825 plate,ASTM B424 Incoloy 825 Plate,3mm Incoloy 825 Plate |
||
| ASME/ASTM Name | ASTM B424 / ASME SB 424 |
| size in mm | 2000 mm x 4000 mm, 1220 mm x 2440 mm, 1000 mm x 2000 mm, 2000 mm x 2000 mm, 1500 mm x 3000 mm, |
| Thickness of Standard Plate | 0.1 to 12 mm Thick |
| Most Frequently Used Form | Strip, Flats, Rolls, Ring (Flange), Coils, Foils, Shim Sheet, Blank (Circle), Plain Sheet |
| Different Finish | Cold rolled sheet (CR), 2B, Hot rolled plates (HR), BA NO(8), SATIN (Met with Plastic Coated), 2D, |
| Hardness Range | Half Hard, Soft, Quarter Hard, Spring Hard, Hard etc |
| Element | Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
| 825 | 8.14 g/cm3 | 1400 °C (2550 °F) | Psi – 80,000 , MPa – 550 | Psi – 32,000 , MPa – 220 | 30 % |
| Grade | C | Mn | Si | S | Cu | Fe | Ni | Cr | Al | Ti |
| 825 | 0.05 max | 1.00 max | 0.5 max | 0.03 max | 1.50 – 3.00 | 22.00 min | 38.00 – 46.00 | 19.50 – 23.50 | 0.02 max | 0.06 – 1.20 |
| STANDARD | WERKSTOFF NR. | UNS | JIS | BS | GOST | AFNOR | EN | OR |
| Incoloy 825 | 2.4858 | N08825 | NCF 825 | NA 16 | ЭП703 | NFE30C20DUM | NiCr21Mo |
