75x10mm S30408 50x10mm Stainless Steel Flat Bar

75x10mm S30408 50x10mm Stainless Steel Flat Bar
75x10mm S30408 50x10mm Stainless Steel Flat Bar 75x10mm S30408 50x10mm Stainless Steel Flat Bar 75x10mm S30408 50x10mm Stainless Steel Flat Bar

Large Image :  75x10mm S30408 50x10mm Stainless Steel Flat Bar

Product Details:
Place of Origin: China
Brand Name: Mittel
Certification: SGS ISO MTC
Model Number: 304
Payment & Shipping Terms:
Minimum Order Quantity: 100KGS
Price: 3.65USD/KG
Packaging Details: Wooden Pallet BOX
Delivery Time: 7 Working Days
Payment Terms: L/C, T/T
Supply Ability: 80000KGS

75x10mm S30408 50x10mm Stainless Steel Flat Bar

Description
Stock: YES,In Stock Grade: 304
Application: Construction,Industry,Steel Grating,ships Building Industry Standard: ASTM,DIN,AISI
Shape: Falt Plate Type: Flat
Technique: Hot Rolled,Cold Drawn Surface: BA/2B/NO.1/NO.3/NO.4/8K/HL/2D/1D
Width: 10mm~500mm Price Term: CIF CFR FOB EX-WORK
High Light:

50x10mm stainless steel flat bar

,

75x10mm stainless steel flat bar

,

S30408 stainless steel flat bar

Stainless Steel 304/304L, UNS S30400

ASTM A276, ASTM A479, ASTM A312, ASTM A213, ASTM A269, ASTM A240, AMS 5639H, ASME SA276, QQ-S-763, Mil-S-862B/1

Farmer's Copper Ltd. is a leading 304L Stainless Steel supplier, maintaining an inventory of Type 304/304L stainless steel in round, square, hex, angles, flat bar, sheet, plate, pipe and tube. 304 is an austenitic stainless steel with non-magnetic properties in the annealed condition that offers good corrosion resistance to both chemical and atmospheric exposures, with a high resistance to oxidation. Type 304/304L has good forming and excellent welding characteristics. It is non-hardenable by heat treatment.

STANDARD SIZES

TYPE

MIN SIZE

MAX SIZE

Round Bar 1/8” dia 11”
Square Bar 1/8” 2”
Hex Bar 3/8” 2”
Angles 1/8” x 1” x 1” 3/8” x 4” x 4”
Flat Bar (thickness)
(width)
1/8”
2”
1/2”
4”
Sheet (304/304L #2B finish)
(304 #4 PVC coated)
26 GA.
24 GA.
10 GA.
10 GA.
Plate (thickness) 3/16” 3”
Pipe 1/4” standard (Sch 40) 4”
Tube 1/8”OD 1-5/8”OD



CHEMICAL ANALYSIS FOR 304 STAINLESS STEEL

CHEMICAL COMPOSITION

ASTM A276
UNS S30400
Type 304
Carbon (%) 0.08
Manganese (%) 2
Phosphorous (%) 0.045
Sulfur (%) 0.03
Silicon, Max (%) 1
Chromium (%) 18.0-20.0
Nickel (%) 8.0-11.0
Molybden (%) --
Nitrogen (%) --
Other Elements (%) --



SPECIFICATIONS

Bar/Shapes – ASTM A276, A479, QQ-S-763
Pipe – ASTM A312
Tube – ASTM A213, A269
Sheet/Plate – ASTM A240



75x10mm S30408 50x10mm Stainless Steel Flat Bar 075x10mm S30408 50x10mm Stainless Steel Flat Bar 1
