Product Details:
|
| Application: | Construction | Technique: | Hot Rolled |
|---|---|---|---|
| Surface Treatment: | Black | Standard: | ASTM,AISI,JIS |
| Length: | 1000-12000mm | Type: | Steel Plate |
| Width: | 1000mm-2000mm | ||
| High Light: | S355J2 N Hot Rolled Steel Plate,Hot Rolled Steel Plate S355 J2+N,Carbon Steel Plate EN 10025 |
||
Hot Rolled Steel Plate S355 J2+N Carbon Steel Plate EN 10025 S355J2 N Steel Plate
S355J2 Steel Plates
S355 – a structural grade steel with a minimum yield strength of 355 N/mm² which widely used in the engineering and construction industries.
S355 offers high yield and tensile strength and is supplied with a variety of treatments and test options to ensure it is a highly usable steel in your various projects.
EN 10025-2 S355J2 High Yield Strength Structural Steel Plate
S355J2+N and S355J2G3 are the same steel grades as both grades delivery condition are normalized. G3 and N stand for normalized.
S symbol for Structural Steel
JR symbol 20 temperature impact test
J0 syambol 0 temperature impact test
J2 symbol -20 temperature impact test
S355J2 Characteristic
S355J2 is a low carbon, high tensile strength structural steel which can be readily welded to other weldable steel. With its low carbon equivalent, it possesses good coldforming properties. The plate is produced by fully killed steel process and supplied in normalized or controlled rolling condition.
S355J2 Application
Structural application in freight cars, transmission towers, dump trucks, cranes, trailers, bull dozers, excavators, forestry machines, railway wagons, dolphins, penstocks, pipes, highway bridges, building structures, oil and gas platforms, offshore structures, shipbuilding, power plant, palm oil equipments and machineries, fans, pumps, lifting equipments and port equipments.
Dimension we could supply:
Thickness 8mm-300mm, Width: 1500-4020mm, Length: 3000-27000mm
S355J2 Delivery Condition: Hot rolled, CR, Normalized, Quenched, Tempering, Q+T, N+T, TMCP, Z15, Z25, Z35
S355J2 Chemical Composition(max %):
| Chemical Composition | C.E. | |||||||||||
| C | Si | Mn | Cr | Mo | Ni | V | W | S | P | CU | ||
|
10025-2:2004 S355J2 |
max 0.22 |
max 0.55 |
max 1.60 |
- | - | - | - | - |
max 0.035 |
max 0.035 |
- |
max 0.047 |
S355J2+N Mechanical Properties:
| Thickness (mm) |
Yield Strength Reh min (N / mm²) |
Tensile Strength Rm min (N / mm²) |
Elongation A5 min (%) |
Impact Values Charpy-V-Notch Longitudinal Average from 3 Speimens Thk. >10<150mm. |
| 3<thk<100 | 315-335 | 490-630 | max 22 | 27 Joules at -20 C |
MITTEL is specialized in low alloy high strength structural steel, mainly dealing with specification standard plates in EN 10025-2, EN 10025-3, EN 10025-4, EN 10025-6, ASTM A633, ASTM A573, ASTM A572, DIN 17100, JIS G3106, ASTM A709, ASTM A283, ASTM A529, ASTM A656, EN 10225, ISO 630, NFA 35-501, and so on, the thickness up to 300mm.
