Food-Grade 304 Stainless Steel Sanitary Tubing, Valve, Fitting 304 Mirror Polished Stainless Steel Seamless Tube

Food-Grade 304 Stainless Steel Sanitary Tubing, Valve, Fitting 304 Mirror Polished Stainless Steel Seamless Tube
Food-Grade 304 Stainless Steel Sanitary Tubing, Valve, Fitting 304 Mirror Polished Stainless Steel Seamless Tube Food-Grade 304 Stainless Steel Sanitary Tubing, Valve, Fitting 304 Mirror Polished Stainless Steel Seamless Tube Food-Grade 304 Stainless Steel Sanitary Tubing, Valve, Fitting 304 Mirror Polished Stainless Steel Seamless Tube

Large Image :  Food-Grade 304 Stainless Steel Sanitary Tubing, Valve, Fitting 304 Mirror Polished Stainless Steel Seamless Tube

Product Details:
Place of Origin: China
Brand Name: Mittel
Certification: SGS ISO MTC
Model Number: 304
Payment & Shipping Terms:
Minimum Order Quantity: 100KGS
Price: 3.65USD/KG
Packaging Details: Wooden Pallet BOX
Delivery Time: 7 Working Days
Payment Terms: L/C, T/T
Supply Ability: 80000KGS

Food-Grade 304 Stainless Steel Sanitary Tubing, Valve, Fitting 304 Mirror Polished Stainless Steel Seamless Tube

Description
Steel Grade: 304 Type: Welded,Seamless
Standard: EN,ASTM Application: Construction,Decoration,Industry
Surface: 8K,Annealed/Pickling/Polished/Brushed/Sand-blasted Finished Thickness: 0.5-4mm
Length: 6 Meters Or Customized Outer Diameter: 6-630mm

Food-Grade Stainless Steel Sanitary Tubing, Valve, Fitting 304 Mirror Polished Stainless Steel Seamless Tube

TP316L/316L Sanitary seamless stainless steel pipe mirror polishing stainless steel pipe



ASTM A270 Sanitary stainless steel tubing as well sanitary stainless steel tube, meets A270 standards available in sanitary stainless steel AISI 316L, 304L or 304 from 1” to 4” sizes, inside roughness ( 32 μ'/0,8 μm ) Ra 180 grit; outside surface finishing ( 150 grit / Brushed ) acording A270. Upon Request Inside surface finishing ( 20 μ'/0,5 μm ) Ra. for ASME SA270 standards. To maintain clean standards tubes are packed individually in plastic sleeves and covered with plastic caps in both ends.




Stainless steel is used by the dairy, food, and other industries because it can be polished to a smooth, hard, relatively inert surface finish that can be maintained in a sanitary condition without degradation by corrosion.



Spezilla sanitary tube is ideal for the dairy food and beverage industries where the highest degree purity and cleanliness is essential. It is certified to the requirements of ASTM A270 standards, and most user specifications.



Our customers have come to rely on the quality of Spezilla’s sanitary tube products as well as our uncompromised commitment to total customer satisfaction. We stock all sanitary tube sizes from ½” to 6.0” OD in 20 ft. standard lengths. Custom lengths and sizes are available upon request. We stock:

  • Type T304L adaptable for brazing or field welding
  • Type T316L corrosion and heat resistant, adaptable for welding, brazing



Description SUS 304 316L 1.4571 schedule 10 Sanitary Seamless Stainless Steel Tube /Pipe
Supply Capacity 10000 tons/Year
Process Method Automatic welding or seamless precision rolling
Out Diameter 6-323.8mm
Wall Thickness 1.0mm.1.2mm 1.5mm.1.65mm.2.0mm.2.1m3.0mm and so on
Length 6m, or as customers demand
Steel Grade
301 (Ni : 6%), 304, TP304, TP304L/304L, 321, TP321, 316, TP316L, 316L,

Standards ASTM A249, A269, A312, A554, A270
Specification O.D: 1/4" - 12" (inch)
W.T: SCH5S, SCH10S
Or non-regular size to be tailored as required.
Application Liquid delivery,for food,dairy, and so on
Packing 1.with plastic cap to protect both ends
2.plastic bag wrapped outside the pipe
3.Plywood case packing

Annealed & Pickled (for sanitary or industial pipe)

Bright Annealed

Polished to 180#, 240#, 320#, 400#

Certificate ISO 9001:2008 for SUS 304 316L 1.4571 schedule 10 Sanitary Seamless Stainless Steel Tube /Pipe
Delivery time 30-60 days depend on Quantity
Payment Term T/T, Irrevocable L/C at sight
Trade Term FOB , CFR , CIF



Advantages 1.Certificated by ISO,PED,TUV
  2.Third party inspection such as TUV,BVmLloyd’s,SGS
  3.Raw material from Bao Steel
  4.Specialist with more than 7 year experience
  5.Competitive price with reliable quality



Chemical Composition ASTM A270 Stainless Steel Sanitary Pipe
Elements 304L(wt%) 316L(wt%)
C Max. 0.035 0.035
Mn Max. 2.00 2.00
P Max. 0.040 0.040
S Max. 0.030 0.030
Si Max. 0.75 0.75
Ni 8.0-13.0 10.00-15.00
Cr 18.0-20.0 16.00-18.00
Mo N/A 2.0-3.0
Fe Bal. Bal.
Cu N/A N/A
N N/A N/A

Food-Grade 304 Stainless Steel Sanitary Tubing, Valve, Fitting 304 Mirror Polished Stainless Steel Seamless Tube 0Food-Grade 304 Stainless Steel Sanitary Tubing, Valve, Fitting 304 Mirror Polished Stainless Steel Seamless Tube 1Food-Grade 304 Stainless Steel Sanitary Tubing, Valve, Fitting 304 Mirror Polished Stainless Steel Seamless Tube 2
