CS ASTM A516 Gr.70 Alloy Steel Plate EN 10204 3.1 SA 516 Grade 60 ASME

CS ASTM A516 Gr.70 Alloy Steel Plate EN 10204 3.1 SA 516 Grade 60 ASME
CS ASTM A516 Gr.70 Alloy Steel Plate EN 10204 3.1 SA 516 Grade 60 ASME CS ASTM A516 Gr.70 Alloy Steel Plate EN 10204 3.1 SA 516 Grade 60 ASME CS ASTM A516 Gr.70 Alloy Steel Plate EN 10204 3.1 SA 516 Grade 60 ASME

Large Image :  CS ASTM A516 Gr.70 Alloy Steel Plate EN 10204 3.1 SA 516 Grade 60 ASME

Product Details:
Place of Origin: China
Brand Name: Mittel
Certification: SGS ISO MTC
Model Number: A516 Gr.70
Payment & Shipping Terms:
Minimum Order Quantity: 100KGS
Price: 0.85 USD/KG
Packaging Details: Wooden Pallet BOX
Delivery Time: 7 Working Days
Payment Terms: L/C, T/T
Supply Ability: 80000KGS

CS ASTM A516 Gr.70 Alloy Steel Plate EN 10204 3.1 SA 516 Grade 60 ASME

Description
Application: Boiler Plate Technique: Hot Rolled
Surface Treatment: Black Standard: ASTM,GB,AISI,JIS,DIN
Length: 1000-12000mm Type: Steel Plate
Width: 600mm-1250mm Special Use: Alloy Structual Steel
Thickness: 2-100mm Price Term: CIF CFR FOB EX-WORK
High Light:

CS ASTM A516 alloy steel plate

,

ASTM A516 Gr.70 alloy steel plate

,

EN 10204 alloy steel plate

ASTM A516 Gr 70 VS A36, ASTM A516 steel and A36 steel actually belong to different steel types. ASTM A516 steel is pressure vessel and boiler steel. ASTM A36 steel is mild steel. For the chemical content of carbon, ASTM A516 steel and A36 steel are also called carbon steel. But their properties have obvious difference.

ASTM A516 Gr 70 VS A36 carbon steel plate in chemical composition:
ASTM A36 carbon steel plate chemical composition:

Grade C (t≤16mm) Si Mn P S
A36 0.26 max 0.40 max - 0.040 max 0.050 max

ASTM A516 Gr 70 carbon steel plate chemical composition:

Chemical elements Percentage % Chemical elements Percentage %
C 0.10/ 0.22 Cu 0.30
Si 0.6 Ni 0.30
Mn 1/ 1.7 Mo 0.08
P 0.03 Nb 0.01
S 0.03 Ti 0.03
Al 0.02 V 0.02
Cr 0.3

ASTM A516 Gr 70 VS A36 carbon steel plate in mechanical properties:
ASTM A36 carbon steel plate mechanical properties:

Grade Yield strength ReH/(N/mm2) Tensile strength Rm/(N/mm2)
(3mm≤t≤16mm)
Elongation A/%
(t≤16mm) min (3mm≤t≤40mm) min
A36 250 400-550 23

ASTM A516 Gr 70 carbon steel plate mechanical properties:

Grade Tensile strength
(MPa)
Minimum yield
strength (MPa)
Minimum elongation (%) gauge length
50mm 200mm
A516 Gr 70 485 - 620 260 21 17

ASTM A516 Gr 70 VS A36 carbon steel plate in application:
ASTM A36 carbon steel plate is used in heavy machinery, industrial boilers, wagon tippers, feeders, stackers, crushers, loaders, cranes, shipping industry and supporting frames for equipment used in metallurgical and other heavy industries.

ASTM A516 Gr 70 steel plate is mainly used for pressure vessel and boiler, oil and gas as well as petrochemical industries.



CS ASTM A516 Gr.70 Alloy Steel Plate EN 10204 3.1 SA 516 Grade 60 ASME 0CS ASTM A516 Gr.70 Alloy Steel Plate EN 10204 3.1 SA 516 Grade 60 ASME 1CS ASTM A516 Gr.70 Alloy Steel Plate EN 10204 3.1 SA 516 Grade 60 ASME 2
