ASTM A106 Grade C Carbon Seamless Steel Pipe Outter Dia = 273mm Wall Thickness 14mm For Boiler

ASTM A106 Grade C Carbon Seamless Steel Pipe Outter Dia = 273mm  Wall Thickness 14mm For Boiler
ASTM A106 Grade C Carbon Seamless Steel Pipe Outter Dia = 273mm  Wall Thickness 14mm For Boiler ASTM A106 Grade C Carbon Seamless Steel Pipe Outter Dia = 273mm  Wall Thickness 14mm For Boiler ASTM A106 Grade C Carbon Seamless Steel Pipe Outter Dia = 273mm  Wall Thickness 14mm For Boiler

Large Image :  ASTM A106 Grade C Carbon Seamless Steel Pipe Outter Dia = 273mm Wall Thickness 14mm For Boiler

Product Details:
Place of Origin: China
Brand Name: Mittel
Model Number: ASTM A106 Grade C
Payment & Shipping Terms:
Minimum Order Quantity: 100KGS
Price: 0.85 USD/KG
Packaging Details: Wooden Pallet
Delivery Time: 7 Working Days
Payment Terms: L/C, T/T
Supply Ability: 80000KGS

ASTM A106 Grade C Carbon Seamless Steel Pipe Outter Dia = 273mm Wall Thickness 14mm For Boiler

Description
Certification: API,ISO9001-2000,ISO-9001 Grade: A53 A106C
Alloy Or Not: Non-alloy Technique: Hot Rolled
Standard2: ASTM A106-2006 Thickness: 6 - 150 Mm
Application: Structure Pipe,Oil Pipe,Gas Pipe Standard: API,ASTM,DIN
Special Pipe: API Pipe Section Shape: Round
Outer Diameter(round): 10.3 - 720 Mm Length: 5.8-12m
Shape: Round Shape
High Light:

heavy steel pipe

,

structural steel pipes

ASTM A106 Seamless Steel Pipe Specifications

ASTM A106 pipe (also covered in ASME specifications as S/A 106) is the standard specification for seamless carbon steel pipe for high-temperature service. Most common uses are in refineries and plants when gasses or fluids are transported at high temperatures and pressures. Federal Steel Supply is a world leader in the supply of A106 / SA 106 pipe and stocks a full range of grades B/C in a size rage of NPS 1/8″ to NPS 48″, with nominal (average) wall thickness as given in ANSI B36.10. Pipe having other dimensions may be furnished provided such pipe complies with all other requirements of this specification*. Pipe ordered under this specification shall be suitable for bending, for flanging, for welding, and for similar forming operations. A full range of A106 stock is available in Schedules 10 through 160, STD, XS, XXS. Unscheduled wall thicknesses available up to 4 inches.

Federal Steel Supply stocks a full range of A106 seamless carbon steel pipe.

Grades B/C

Sizes

NPS 1/8″ to NPS 48”
Wall thickness: Schedules 10 through 160, STD, XS, XXS.

*Commonly requested unscheduled walls up to 4” and certified minimum wall items



Chemical Properties %

  C, max. Mn P, max S, max Si, min Cr, max Cu, max Mo, max Ni, max V, max
Grade A * 0.25 0.27 – 0.93 0.035 0.035 0.10 0.40 0.40 0.15 0.40 0.08
Grade B 0.30 0.29 – 1.06 0.035 0.035 0.10 0.40 0.40 0.15 0.40 0.08
Grade C 0.35 0.29 – 1.06 0.035 0.035 0.10 0.40 0.40 0.15 0.40 0.08

*For each reduction of 0.01% below the specified carbon maximum, an increase of 0.06% manganese above the specified maximum will be permitted up to a maximum of 1.35%.

Mechanical Properties

  Grade A Grade B Grade C
Tensile Strength, min., psi, (MPa) 48,000 (330) 60,000 (415) 70,000 (485)
Yield Strength, min., psi, (MPa) 30,000 (205) 35,000 (240) 40,000 (275)

(Note: This is summarized information from ASME Specification A106. Please refer to the specific Standard or Specification or contact us for more details.)
