BE ASME Super Duplex Stainless Steel Tube B36.19/10 ASTM A 790 UNS S32760

BE ASME Super Duplex Stainless Steel Tube B36.19/10 ASTM A 790 UNS S32760
BE ASME Super Duplex Stainless Steel Tube B36.19/10 ASTM A 790 UNS S32760 BE ASME Super Duplex Stainless Steel Tube B36.19/10 ASTM A 790 UNS S32760

Large Image :  BE ASME Super Duplex Stainless Steel Tube B36.19/10 ASTM A 790 UNS S32760

Product Details:
Place of Origin: China
Brand Name: MITTEL
Certification: SGS BV
Model Number: S32760
Payment & Shipping Terms:
Minimum Order Quantity: 100KGS
Price: 8.5 USD/KG
Packaging Details: Wooden Box
Delivery Time: 7 Days
Payment Terms: L/C, T/T
Supply Ability: 80000KGS

BE ASME Super Duplex Stainless Steel Tube B36.19/10 ASTM A 790 UNS S32760

Description
Application: Construction,Decoration,Industry,boiler,Chemical Standard: GB,DIN,ASTM,JIS,AISI
Type: Seamless Thickness: 1-30mm
Length: 3000mm~6000mm,Customer Request Shape: Round.square.Rectangle
Outer Diameter: 8-630mm Technique: Cold Drawn
Surface: Annealing,pickling
High Light:

ss seamless pipes

,

astm stainless steel pipe



BE ASME Super Duplex Stainless Steel Tube B36.19/10 ASTM A 790 UNS S32760



S32760, also called F55 or 1.4501, is a high-alloy super duplex stainless steel, featuring strong strength

and corrosion resistance, mainly used in a variety of strong corrosion environments such as chemical

processing, petrochemical and submarine equipment.

Features of Inox F55

S32760 duplex steel also features strong resistance to chloride corrosion, high thermal conductivity

and low coefficient of thermal expansion. Higher chromium, molybdenum and nitrogen content make

it highly resistant to pitting, crevice corrosion and other corrosions. The excellent overall performance

of S32760 duplex steel is superior to that of general dual phase steel, such as 2205, S31803 and so on.

S32760 duplex steel is resistant to various inorganic acids and organic acids. The copper added makes

it resistant to non-oxidative acid corrosion. S32760 is also resistant to strong alkali corrosion, but it is not

suitable to work at temperatures above 300 ° C for a long time, because a long-term exposure to such

high temperature will lead to reduced toughness of the material.

S32760 stainless steel was used as cast steel in the early 1980s to make up the insufficient corrosion

resistance of the second-generation duplex stainless steel 00Cr22Ni5Mo2N (2205). In the late 1980s,

it came to be used as the deformable material for pipeline systems. Subsequently, this super duplex

was introduced as an important corrosion-resistant material into oil and gas development, seawater

environment, flue gas desulfurization (FGD), desalination, and chemical applications.

S32760 stainless steel also contains a small amount of tungsten and copper in addition to high chromium,

molybdenum and nitrogen. In early times, tungsten and copper were added to improve the casting

properties of this alloy. Later, it was found that tungsten and copper could enhance the corrosion

resistance of the steel in certain acids and its ability to passivate in seawater.

Just like other super duplex stainless steels, S32760 stainless steel microstructure presents a

two-phase structure with α/γ close to 1 under solid solution conditions. However, undergoing

from high temperature to room temperature like incorrect thermal processing, heat treatment and

welding process, during which cooling processes, there will be intermetallic phases and nitrides

on the substrate of S32760 stainless steel. When exposed to temperature at around 900 °C for more

than 100 seconds, σ, χ, Cr2N, etc. will precipitate on the substrate; at about 475 °C for more than

800 seconds, the α phase will precipitate. In order to avoid the precipitation of the intermetallic

phase and the Cr2N phase, it must have a sufficient cooling rate during the cooling process.

Plus, this super duplex stainless steel does not adapt to heat treatment and cooling to produce σ phase.

Alloy Super Duplex S32760
Material No. 1.4501
EN symbol (short) X2CrNiMoCuWN25-7-4
UNS UNS S32760
Registered work label
Norm/Standard
ASTM A182 F55

UNS S32760

Chemical Composition

C
%
Cr
≤ %
Cu
≤ %
Fe Mo
%
Mn
%
N
%
Ni
%
0.030 Max 24.0<26.0 0.5<1.0 Remainder 3.0<4.0 1.0 max 0.20<0.30 6.0<8.0
P
%
S
%
Si
≤%
W
%

0.030 max 0.010 max 0.010 max 0.50< 1.00

S32760 Applications

  • 1) Neutral chloride environment;
  • 2) Oil refining industry;
  • 3) Pipeline used for chemical industry;
  • 4) Oil and gas industry;
  • 5) Pulp and paper industry;
  • 6) Fertilizer industry, urea industry, phosphate fertilizer industry;
  • 7) Seawater environment, energy and environmental protection industry;
  • 8) Light industry and food industry, food and pharmaceutical industry equipment;
  • 9) High strength structural parts;
  • 10) Hood desulfurization, infiltration desalination equipment, sulfuric acid plant;
  • 11) Submarine pipelines, marine engineering fasteners, etc.;
  • 12) Others.

BE ASME Super Duplex Stainless Steel Tube B36.19/10 ASTM A 790 UNS S32760 0BE ASME Super Duplex Stainless Steel Tube B36.19/10 ASTM A 790 UNS S32760 1BE ASME Super Duplex Stainless Steel Tube B36.19/10 ASTM A 790 UNS S32760 2
