Product Details:
|
| Steel Grade: | 304 | Type: | Welded,Seamless |
|---|---|---|---|
| Welding Line Type: | Seamless,ERW,EFW | Standard: | EN,ASTM |
| Application: | Construction,Decoration,Railing & Baluster Constrcution Decoration | Shape: | Round.square.Rectangle |
| Surface: | Annealing,8K | Product Name: | 304 316 Welded Slotted Pipes |
| Length: | 6 Meters Or Customized | Outer Diameter: | 6-630mm |
| Finish: | Bright,Brush Polish,180# 320#400# | Price Term: | CIF |
| Trade Terms: | FOB CIF CFR CNF EXWORK | ||
| High Light: | stainless steel pipe astm,stainless steel pipe welding standards |
||
| Name | Stainless steel sanitary pipe | |||||
| Items |
Square welded pipes, round welded pipes, oval welded pipes, special shaped welded pipes empaistic welded pipes, fittings |
|||||
| Standard | ASTM A554, A249, A269 and A270 | |||||
| Material Grade | 201: Ni 0.8%~1% | |||||
| 304: Ni 8%, Cr 18% | ||||||
| 316L: Ni10%~16% | ||||||
| Outer Diameter | 6mm--159mm | |||||
| Thickness | 1.0mm - 4.0mm | |||||
| Length | 6m or as customers' request | |||||
|
Tolerance |
a) Outer Diameter: +/- 0.2mm | |||||
| b) Thickness: +/- 0.02mm | ||||||
| c) Length: +/- 5mm | ||||||
| Surface |
180G, 320G, 400G Satin / Hairline 400G, 500G, 600G or 800G Mirror finish |
|||||
| Application | handrail,railing, weldmesh screen, staircase, door,window, balcony,fence,bench,furniture,etc | |||||
| Test | Squash test, extended test, water pressure test, crystal rot test, heat treatment, NDT | |||||
|
Chemical Composition of Material |
Material Composition |
201 | 202 | 304 | 316L | 430 |
| C | ≤0.15 | ≤0.15 | ≤0.08 | ≤0.035 | ≤0.12 | |
| Si | ≤1.00 | ≤1.00 | ≤1.00 | ≤1.00 | ≤1.00 | |
| Mn | 5.5-7.5 | 7.5-10 | ≤2.00 | ≤2.00 | ≤1.00 | |
| P | ≤0.06 | ≤0.06 | ≤0.045 | ≤0.045 | ≤0.040 | |
| S | ≤0.03 | ≤0.03 | ≤0.030 | ≤0.030 | ≤0.030 | |
| Cr | 13-15 | 14-17 | 18-20 | 16-18 | 16-18 | |
| Ni | 0.7-1.1 | 3.5-4.5 | 8-10.5 | 10-14 | ||
| Mo | 2.0-3.0 | |||||
|
Mechanical Property |
Material Item | 201 | 202 | 304 | 316 | |
| Tensile Strength | ≥535 | ≥520 | ≥520 | ≥520 | ||
| Yield Strength | ≥245 | ≥205 | ≥205 | ≥205 | ||
| Extension | ≥30% | ≥30% | ≥35% | ≥35% | ||
| Hardness (HV) | <105 | <100 | <90 | <90 | ||
Usage: Milk and food industry, pharmaceutical industry, special inner surface requirements of the industry.
Process characteristics: inner bead leveling treatment, solution treatment, inner surface electropolishing
Performance characteristics: the internal surface roughness Ra is more than 0.2, the wall hanging residue is small, easy to clean, prevent bacterial growth, electrolytic polishing has a passivation effect, and the inner wall has good defense performance.
Testing methods: lateral, longitudinal flattening, reverse flattening, hydrostatic testing or eddy current testing, mechanical properties testing, internal surface roughness testing.
