17-7PH SUS631 S17700 DIN1.4568 Stainless Steel Seamless Tube Stainless Steel Hollow Pipe

17-7PH SUS631 S17700 DIN1.4568 Stainless Steel Seamless Tube Stainless Steel Hollow Pipe
17-7PH SUS631 S17700 DIN1.4568 Stainless Steel Seamless Tube Stainless Steel Hollow Pipe 17-7PH SUS631 S17700 DIN1.4568 Stainless Steel Seamless Tube Stainless Steel Hollow Pipe 17-7PH SUS631 S17700 DIN1.4568 Stainless Steel Seamless Tube Stainless Steel Hollow Pipe 17-7PH SUS631 S17700 DIN1.4568 Stainless Steel Seamless Tube Stainless Steel Hollow Pipe 17-7PH SUS631 S17700 DIN1.4568 Stainless Steel Seamless Tube Stainless Steel Hollow Pipe

Large Image :  17-7PH SUS631 S17700 DIN1.4568 Stainless Steel Seamless Tube Stainless Steel Hollow Pipe

Product Details:
Place of Origin: China Jiangsu
Brand Name: MITTEL
Certification: SGS ISO MTC
Model Number: 17-7PH
Payment & Shipping Terms:
Minimum Order Quantity: 50KGS
Price: 7.45 USD/KG
Packaging Details: Export Packing
Delivery Time: 14 DAYS
Payment Terms: L/C, T/T
Supply Ability: 50000KGS

17-7PH SUS631 S17700 DIN1.4568 Stainless Steel Seamless Tube Stainless Steel Hollow Pipe

Description
Application: Construction,Decoration,Industry,Chemical Standard: DIN,ASTM,AISI
Steel Grade: 17-7PH Type: Seamless
Welding Line Type: Seamless Thickness: 1mm-20mm
Length: 3000mm~6000mm,Customer Request Shape: Round.square.Rectangle
Outer Diameter: 6-762mm Technique: Cold Drawn
Surface: Annealing Material: Stainless Steel
Color: Customerized
High Light:

seamless stainless steel tube

,

astm stainless steel pipe

17-7PH SUS631 S17700 DIN1.4568 Stainless Steel Seamless Tube Stainless Steel Hollow Pipe



17-7 PH is a precipitation-hardened stainless steel that is well suited for aerospace and other applications requiring high strength and good corrosion resistance and formability. Type 17-7PH is a Chromium-Nickel-Aluminum, austenitic stainless steel. It is the most formable of all PH grades and has the highest strength and hardness. It is less magnetic than other PH grades and offers minimal distortion upon heat treatment. This material maintains its valuable properties at temperatures up to 800° F (427° C).


  • 17-7 ph
  • UNS S17700
  • AMS 5528
  • ASTM A 693
  • ASME SA 693
  • W.NR 1.4541
  • PWA-LCS
  • GE-S400/1000
  • RR SABRe Edition 2
  • DFARS Compliant
  • SAE AMS 5528

Common Trade Names

  • 17-7
  • ATI 17-7 (™ Allegheny Technologies)
  • T-17-7 Stainless Steel (ThyssenKrupp VDM)

Inventory Size Range

  • Sheet : 0.018" - 0.187"
  • Plate : 0.018" - 0.187"

Please contact us for more details.
The technical data provided is for information only and not for design purposes. It is not warranted or guaranteed.

For a deeper understanding of the difference between 17-4 PH and 17-7 PH precipitation hardening alloys, request our white paper on the topic.

17-7PH Chemical Composition

Element Percent By Weight
Type 17-7ph
C Carbon 0.09 maximum
Mn Manganese 1.00 maximum
P Phosphorus 0.05 maximum
S Sulfur 0.03 maximum
Si Silicon 1.00 maximum
Cr Chromium 16.00 - 18.00
Ni Nickel 6.75 - 7.75
Al Aluminum 0.75 - 1.50

Common Applications of 17-7 PH Stainless Steel

  • Aerospace applications
  • Chemical processing equipment
  • Oil and petroleum refining equipment
  • Food grade stainless steel for processing equipment
  • General metalworking



17-7PH Physical Properties

  • Melting Range: 2560-2625°F (1404-1440°C)
  • Density: 0.2820 lb/in³

Mean Coefficient of Thermal Expansion

(Annealed Condition)

Temperature Range Mean Coefficient of Thermal Expansion
°C °F μm/m°C in/in/°F·10⁶
21-93 70-200 15.3 8.5
21-204 70-400 16.2 9.0
21-316 70-600 17.1 9.5
21-427 70-800 17.3 9.6



Thermal Conductivity (TH 1050 Condition)

Temperature Range Coefficients
°C °F W/m·K Btu/(hr/ft²/in/°F)
149 300 16.87 117
260 500 18.46 128
449 840 21.05 146
482 900 21.05 146



Magnetic Permeability (Annealed Condition)

Oersteds AT/m μ
25 1989 1.4 - 3.4
50 3878 1.4 - 3.6
100 7956 1.4 - 3.5
200 15.912 1.4 - 3.2
max max 1.4 - 3.6

Electrical Resistivity (Annealed Condition)

  • Microhm-cm: 80

Mechanical Properties and Yield Strength of 17-7PH

Room Temperatures (Annealed)

  • Ultimate Tensile Strength psi (MPa): 130,000 (896)
  • 0.2% Tensile Yield Strength psi (MPa): 40,000 (276)
  • Elongation % in 2" (50mm): 35
  • Hardness Rockwell: B85
  •

 17-7PH SUS631 S17700 DIN1.4568 Stainless Steel Seamless Tube Stainless Steel Hollow Pipe 017-7PH SUS631 S17700 DIN1.4568 Stainless Steel Seamless Tube Stainless Steel Hollow Pipe 117-7PH SUS631 S17700 DIN1.4568 Stainless Steel Seamless Tube Stainless Steel Hollow Pipe 217-7PH SUS631 S17700 DIN1.4568 Stainless Steel Seamless Tube Stainless Steel Hollow Pipe 317-7PH SUS631 S17700 DIN1.4568 Stainless Steel Seamless Tube Stainless Steel Hollow Pipe 4
