ASTM /ASME SA790 S32205 Stainless Steel Pipe UNS S31803 Duplex Steel Tube

ASTM /ASME SA790 S32205 Stainless Steel Pipe UNS S31803 Duplex Steel Tube
ASTM /ASME SA790 S32205 Stainless Steel Pipe UNS S31803 Duplex Steel Tube ASTM /ASME SA790 S32205 Stainless Steel Pipe UNS S31803 Duplex Steel Tube ASTM /ASME SA790 S32205 Stainless Steel Pipe UNS S31803 Duplex Steel Tube ASTM /ASME SA790 S32205 Stainless Steel Pipe UNS S31803 Duplex Steel Tube ASTM /ASME SA790 S32205 Stainless Steel Pipe UNS S31803 Duplex Steel Tube

Large Image :  ASTM /ASME SA790 S32205 Stainless Steel Pipe UNS S31803 Duplex Steel Tube

Product Details:
Place of Origin: China
Brand Name: MITTEL
Certification: SGS MT C
Model Number: 2205
Payment & Shipping Terms:
Minimum Order Quantity: 500KGS
Price: 4.85 USD/KG
Packaging Details: Export Packing
Delivery Time: 10 Days
Payment Terms: L/C, T/T
Supply Ability: 5000Tons

ASTM /ASME SA790 S32205 Stainless Steel Pipe UNS S31803 Duplex Steel Tube

Description
Application: Industry Boiler Chemical Standard: DIN ASTM
Steel Grade: S31803/S32205 Duplex Type: Seamless
Welding Line Type: Seamless Thickness: 1-50mm
Length: 3000mm~6000mm Shape: Round.square.Rectangle
Outer Diameter: 6-630mm Technique: Cold Rolled Hot Rolled
Product Name: Seamless Stainless Steel Pipes Square Tube Surface: Annealing
Material: Stainless Steel Finish: NO.1
Color: Customerized
High Light:

ss seamless pipes

,

astm stainless steel pipe

Material Grade S32205 , S31803 , S32304 , S32750, F51 , F53 , 2205 , 2507 etc
Outer Diameter 10.3mm - 1219mm
Wall Thickness 1.24mm - 54.59mm
Length as per customer’s requirement
Standard ASTM A789 ; ASTM A790 ; EN 10216-5ect .



Application :



1 . Petroleum

2 . Chemical industry

3 . Instrument

4 . Industrial transportation

5 . Mechanical structure industry

6 . Need high corrision ability pipe's industry , such as offshore industry etc



Chemical Composition
Grade C Si Mn P S Cr Ni Mo N
max max max max max
UNS S32750 0.03 0.8 1.2 0.03 0.015 24.0-26.0 6.0-8.0 3.0-5.0 0.24-0.32
UNS S31803 0.03 1 2 0.02 0.02 21.0-23.0 4.5-6.5 2.5-3.5 0.08-0.20
Physical Properties
Grade Y.S.MPa min T.S.Mpa min Elongation % Hardness HRC /
UNS S32750 550 800 15 20 /
UNS S31803 450 620 25 20 /



20ft GP : 5898mm ( Length ) x 2352mm ( Width ) x 2393mm ( High )



40ft GP : 12032mm ( Length ) x 2352mm ( Width ) x 2393mm ( High )



40ft HC : 12032mm ( Lengh ) x 2352mm ( Width ) x 2698mm ( High )



20 feet container load 25tons coils whose length is under 5.8m



40 feet container load 25tons coils whose length is under 11.8m







Duplex stainless steel that was developed to combat common corrosion problems encountered with the 300 series stainless steels . “ Duplex ” describes a family of stainless steels that are neither fully austenitic , like 304 stainless , nor purely ferritic , like 430 stainless . The advantage of a duplex structure is that it combines the favorable qualities of a ferritic alloy ( stress corrosion cracking resistance and high strength ) with those of an austenitic alloy ( ease of fabrication and corrosion resistance ) .

Use UNS32750 super duplex stainless steel pipes can improve corrosion resistance compared to other materials . And super duplex steel pipes have greater tensile and yield strength , good ductility and yield strength , good stress corrosion cracking resistance . Also can help clients reduce their purchase costs , but can gurantee the quality etc .





Welcome everyone who need this kind of pipes contact to me in free . Also MITTEL  can produce stainless steel seamless pipes, bright annealed tubes, seamless coiled tubing etc . You go ahead one step , we can help you creat more profits than your mind .



ASTM /ASME SA790 S32205 Stainless Steel Pipe UNS S31803 Duplex Steel Tube 0ASTM /ASME SA790 S32205 Stainless Steel Pipe UNS S31803 Duplex Steel Tube 1ASTM /ASME SA790 S32205 Stainless Steel Pipe UNS S31803 Duplex Steel Tube 2ASTM /ASME SA790 S32205 Stainless Steel Pipe UNS S31803 Duplex Steel Tube 3ASTM /ASME SA790 S32205 Stainless Steel Pipe UNS S31803 Duplex Steel Tube 4ASTM /ASME SA790 S32205 Stainless Steel Pipe UNS S31803 Duplex Steel Tube 5
