ASTM A240 UNS S32750 Super Duplex Stainless Steel Plates DIN1.4410 Plate

ASTM A240 UNS S32750 Super Duplex Stainless Steel Plates DIN1.4410 Plate
ASTM A240 UNS S32750 Super Duplex Stainless Steel Plates DIN1.4410 Plate ASTM A240 UNS S32750 Super Duplex Stainless Steel Plates DIN1.4410 Plate ASTM A240 UNS S32750 Super Duplex Stainless Steel Plates DIN1.4410 Plate

Large Image :  ASTM A240 UNS S32750 Super Duplex Stainless Steel Plates DIN1.4410 Plate

Product Details:
Place of Origin: Bao Steel ZPSS TISCO
Brand Name: MITTEL
Certification: China
Model Number: S32750
Payment & Shipping Terms:
Minimum Order Quantity: 500KGS
Price: 6.85 USD/KG
Packaging Details: Export Packing
Delivery Time: 14 Days
Payment Terms: L/C, T/T
Supply Ability: 50000KGS

ASTM A240 UNS S32750 Super Duplex Stainless Steel Plates DIN1.4410 Plate

Description
Grade: S32750 2507 1.4410 Thickness: 0.5-100mm
Width: 1000-2000mm Length: 2000-12000mm
Surface: 2B NO.1 Condition: Hot Rolled Cold Rolled
High Light:

stainless steel sheets and plates

,

stainless steel plate thickness



S32750 (2507) is a duplex stainless steel that combines many excellent features of ferritic and austenitic steels. Due to its high chromium and molybdenum content, it embodies excellent resistance to pitting corrosion, crevice corrosion and uniform corrosion. The two-phase microstructure ensures that the steel has high resistance to stress corrosion cracking and high mechanical strength. Besides, it features strong resistance to chloride pitting, high thermal conductivity and low coefficient of thermal expansion.

In comparison with S32205 duplex steel, S32750 features higher strength and corrosion resistance. Compared to 904L, it is more resistant to corrosion caused by dilute sulfuric acid mixed with chloride ions. In contrast with austenitic stainless steel, it features higher yield strength and lower ductility. S32750 super duplex steel also features high impact strength, not suitable for use under temperatures above 570 °F or 300 °C, in that long exposure to such environment will lead to reduced toughness.

Super Duplex 2507 / UNS S32750 Sheets & Plates Specifications

Specifications for Super Duplex 2507 / UNS S32750 Sheets & Plates. If any specification is not mentioned here, please use the contact button for quick quote.

Specifications ASTM A240 / ASME SA240
Thickness 4mm – 100mm
Width 1000mm, 1219mm, 1500mm, 1800mm, 2000mm, 2500mm, 3000mm, 3500mm etc.
Length 2000mm, 2440mm, 3000mm, 5800mm, 6000mm etc.
Surface 2B, 2D, BA, NO.1, NO.4, NO.8, 8K, mirror, checkered, embossed, hairline, sand
Finish Hot rolled plate (HR), Cold rolled sheet (CR), 2B, 2D, BA NO(8), SATIN (Met with Plastic Coated)
Form Coils, Foils, Rolls, Plain Sheet, Shim Sheet, Perforated Sheet, Chequered Plate, Strip, Flats, Blank (Circle), Ring (Flange) etc.



Types of Super Duplex 2507 / UNS S32750 Sheets & Plates



  • Super Duplex Steel S32750 Polished Plates
  • S32750 Super Duplex Steel Polished Plates
  • Super Duplex Steel UNS S32750 Polished Plates
  • Super Duplex Steel WERKSTOFF NR. 1.4410 Polished Plates
  • ASME SA240 2507 Polished Plates
  • Super Duplex Steel S32750 Hot Rolled Plates
  • S32750 Super Duplex Steel Hot Rolled Plates
  • 2507 Super Duplex Steel Hot Rolled Plates
  • Super Duplex Steel WERKSTOFF NR. 1.4410 Hot Rolled Plates





  • ASTM A240 S32750 Super Duplex Steel Hot Rolled Plates
  • Super Duplex Steel S32750 Cold Rolled Plates
  • 2507 Super Duplex Steel Cold Rolled Plates
  • S32750 Super Duplex Steel Cold Rolled Plates
  • Super Duplex Steel UNS S32750 Cold Rolled Plates
  • Super Duplex Steel WERKSTOFF NR. 1.4410 Cold Rolled Plates
  • ASTM A240 S32750 Super Duplex Steel Cold Rolled Plates





            Super Duplex 2507 / UNS S32750 Sheets & Plates Chemical Composition

Grade S32750
C 0.030 max
Mn 1.20 max
Si 0.80 max
P 0.035 max
S 0.020 max
Cr 24.00 – 26.00
Mo 3.00 – 5.00
Ni 6.00 – 8.00
N 0.24 – 0.32
Fe 58.095 min



              Mechanical Properties of Super Duplex 2507 / UNS S32750 Sheets & Plates

Grade S32750
Density (g/cm 3) 7.8
Density (lb/in 3) 0.281
Melting Point (°C) 1350
Melting Point (°F) 2460



   Super Duplex 2507 / UNS S32750 Sheets & Plates – Equivalent Grades

Grade Super Duplex S32750
UNS No S32750
WERKSTOFF NR. 1.4410

Workability of Inox 2507

S32750 needs to be solution annealed and quenched after hot forming or cold forming. When it is done with solution annealing, the temperature should not be lower than 1925 °F, and air or water quenching should be carried out immediately. In order to secure the desired corrosion resistance, the heat treated steel needs to be subjected to pickling and rinsing.

S32750 features good weldability. Many common stainless steel forming methods are also suitable for S32750. It can be welded by a series of methods such as SMAW, GTAW, PAW, FCW, or SAW. When soldering S32750, it is advisable to use 2507/P100 metal, which will form a suitable two-phase structure.

S32750 Applications

  • 1) Desalted plants, high pressure RO plants and submarine pipelines;
  • 2) Offshore platforms, heat exchangers, underwater equipment, firefighting equipment and seawater treatment equipment;
  • 3) Chemical processing industry, utensils and pipeline industry;
  • 4) Mechanical parts (high-strength, corrosion-resistant parts);
  • 5) Oil and gas industry equipment;
  • 6) Corrosion resistant parts of chemical tankers;
  • 7) Energy industry FGD system, industrial scrubbing system, absorption tower;
  • 8) Refining, fertilizer and paper;
  • 9) Others.

Tags

Grade 2507, Type 2507, Inox 2507, SAF 2507, Grade S32750, Type S32750, Inox S32750, 1.4410, UNS S32750, NAS 74N, F53, Acero 2507.

Contact

If you want to buy S32750 stainless steel products, please contact the RIGHT supplier - Mittel  to get the latest price.
