Product Details:
|
| Thickness: | 0.5-100mm | Width: | 1000-3000mm |
|---|---|---|---|
| Length: | 2000-12000mm | Surface: | 2B NO.1 |
| Type: | Hot Rolled And Cold Rolled | ||
| High Light: | precision ground stainless steel plate,stainless steel plate thickness |
||
1.4529 Stainless Steel Equivalent 1.4529 Material Data Sheet Alloy 926 UltrAL-6XN En1.4529 Plate
1.4529 AL6XN 5mm thick stainless steel perforated sheet prime quality
|
Product Name
|
Stainless steel sheet(cold rolled or hot rolled)
|
|
Standard
|
JIS,ASTM,AISI,SUS,UNS,DIN,EN etc
|
|
Thickness
|
Cold rolled:0.15mm-10mm
Hot rolled: 3.0mm-180mm |
|
Width
|
10-2500mm
|
|
Length
|
0.5m-10m
|
|
Surface
|
2B, BA, HL, MIRROR, NO. 1-NO. 4, 8K, and so on.
|
|
Technique
|
Cold Rolled,Hot Rolled and solution annealed
|
|
Material
|
mainly201, 202, 304, 304L, 316, 316L,316Ti,2205,630,321, 310S, 410, 410S, 430, 347H, 2Cr13, 3Cr13 etc
300series:301,302,303,304,304L,309,309s,310,310S,316,316L,316Ti,317L,321,347 200series:201,202,202cu,204 400series:409,409L,410,420,430,431,439,440,441,444 Others:2205,2507,2906,330,660,630,631,17-4ph,17-7ph, S318039 904L,etc Duplex stainless steel:S22053,S25073,S22253,S31803,S32205,S32304 Special Stainless Steel:904L,347/347H,317/317L,316Ti,254Mo |
EN 1.4529
AISI 926
UNS N08926
DIN X1NiCrMoCuN25-20-7
Structure Super-Austenitic
Plates
Strips
Coils
Forgings
Flat bars
Sheets
C: max. 0,02%
Cr: 19,0-21,0%
Cu: 0,50-1,50%
Mn: max. 1,00%
Mo: 6,00-7,00%
Ni: 24,0-26,0%
P: max. 0,030%
S: max. 0,010%
Si: max. 0,50%
Balance: N 0,15-0,25%
Plant manufacturing
Petro chemical
Construction
Ship building
Machine engineering
Plate, cold rolled
Plate, hot rolled
Roundbar, rolled
Flatbar, cold rolled
welded pipe/ welded tube
Forgings
laser cuts
plasma cuts
waterjet cuts
saw cuts
Rings
Discs
Tailormade drawings
Bored roundbars
We are involved in offering a wide range of 1.4529 Plates.
1.4529 Chemical Composition
Carbon; 0.02max
Manganese; 1.00max
Phosphorus; 0.030max
Sulfur; 0.010max
Silicon; 0.5max
Chromium; 19.0-21.0
Molybdenum; 6.0-7.0
Nitrogen; 0.15-0.25
Nickel; 24.0-26.0
Copper; 0.5-1.5
1.4529 Mechanical Properties
Tensile Strength (Mpa); 650-850
0.2% Proof Strength (Mpa); 300-340
Elongation; 35-40%
Valued and appreciated among our clients for trading and supplying a wide range of Ferrous & Non Ferrous Products, an ISO 9001: 2008 certified JIANGSU MITEEL STEEL INDUSTRIAL LIMITED started its operations in the year 2007. Inclusive of Stainless Steel Sheets, Stainless Steel Plates and Stainless Steel Coils, we offer high grade steel products. To ensure high standards of quality, the offered stainless steel sheets and plates are procured from trusted and reliable vendors of the China. Owing to their resistance against corrosion & abrasion, smooth edges, high tensile strength, durable construction, these stainless steel products are highly demanded in the market.
For meeting the precise needs and demands of our clients, we offer this range in various sizes, shapes, thicknesses and dimension. We work to attain maximum customer approval by following transparency in all the business dealings.
