Product Details:
|
| Certification: | CE, ISO, BV, SGS | Stock: | Always In Good Stock |
|---|---|---|---|
| Application: | Industry | Thickness: | 0.25-3mm |
| Material: | 637, 5383, 718 | Grade: | Gr1 |
| Type: | Seamless | Shape: | Round Section |
| Product Name: | Inconel 925 Pipe For Oil And Gas | Sample: | Allowed |
| Standard: | ASTM, AISI, JIS, DIN, EN, GB | ||
| High Light: | carbon steel seamless pipe,structural steel pipes |
||
ASME sb 637 5383 CAST 718 Inconel Pipe/tube Inconel 901 Alloy Pipe
| Tensile Strength | 965 MPa min | 140,000 psi min |
| Yield Strength | 758 MPa min | - |
| 110,000 psi min | - | |
| - | ||
| Total Elongation Under Load | 20.000 % | - |
| Hardness | 38 Max HRC | - |
Under ISO9001, we own a set of complete and effective quality system in our factory. Authorized by the American Petroleum Institute, Anson steel is awarded API 5CT production certificate.
Furthermore, we has strict inspection and test system before shipping including dimensional inspection, strength test, tensile test, hardness test, hydrostatic test etc.
Therefore, our API 5CT well casing has enough quality assurance to eliminate your worries.
Technical specification can accroding to GB/ASTM ect STandards
Incoloy 901 Chemical composition:
| Alloy | % | Ni | Cu | Al | Fe | Ti | Co | Mn | S | C | Si | P | Cr | Mo | B |
| Incoloy 901 | Min. | 40.0 | 2.35 | 11.0 | 5.0 | 0.01 | |||||||||
| Max. | 45.0 | 0.50 | 0.35 | Balance | 3.10 | 1.0 | 1.0 | 0.03 | 0.10 | 0.60 | 0.03 | 14.0 | 7.0 | 0.02 |
Incoloy 901 Physical properties:
| Density | 8.14 g/cm3 |
| Melting point | 1280-1345°C |
Incoloy 901 minimum mechanical properties( in the room temperature):
| Status | Tensile strength Rm N/mm2 |
Yield strength RP0.2N/mm2 |
Elongation A5 % |
| Incoloy 901 | 1034 | 689 | 12 |
Inconel 901 Description
A nickel-iron-chromium alloy containing titanium and aluminum for precipitation hardening and molybdenum for solid-solution strengthening. The alloy has high yield strength and creep resistance at temperatures to about 1110°F (600°C). A subtantial iron content enables the alloy to combine high strength with good forging characteristics. Used in gas turbines for discs and shafts. Standard products form is round.
Corrosion Resistance
Alloy 901 has good corrosion resistance to the atmospheres normally found in jet engine operations. It has slightly lower scaling resistance than such alloy as Types 309 and 310 stainless steel.
A: Some items accept this service, pls contact us for details.
Products finished
