ASTM A240 / A240M AISI 316LN DIN 1.4429 Stainless Steel Sheets And Plates 2B And NO.1 Finish

ASTM A240 / A240M AISI 316LN DIN 1.4429 Stainless Steel Sheets And Plates 2B And NO.1 Finish
ASTM A240 / A240M AISI 316LN DIN 1.4429 Stainless Steel Sheets And Plates 2B And NO.1 Finish ASTM A240 / A240M AISI 316LN DIN 1.4429 Stainless Steel Sheets And Plates 2B And NO.1 Finish

Large Image :  ASTM A240 / A240M AISI 316LN DIN 1.4429 Stainless Steel Sheets And Plates 2B And NO.1 Finish

Product Details:
Place of Origin: China
Brand Name: TISCO BAO STEEL
Certification: SGS
Model Number: 316LN
Payment & Shipping Terms:
Minimum Order Quantity: 1 tons
Price: 4350 usd/ton
Packaging Details: export packing
Delivery Time: 7 days
Payment Terms: L/C, T/T
Supply Ability: 500 tons

ASTM A240 / A240M AISI 316LN DIN 1.4429 Stainless Steel Sheets And Plates 2B And NO.1 Finish

Description
Thickness: 0.5-150mm Width: 1000-2000mm
Length: 2000-6000mm Surface: 2B NO.1 2D BA
Type: Hot Rolled And Cold Roleld
High Light:

precision ground stainless steel plate

,

stainless steel plate thickness

ASTM A240/A240M AISI 316LN DIN 1.4429 Stainless Steel Plate 2B and NO.1 Finish

316LN (UNS S31653) is a lowcarbon, nitrogen-enhanced version of Type 316 molybdenum-bearing austenitic stainless steel. The Type 316 alloys are more resistant to general corrosion and pitting/crevice corrosion than the conventional chromium-nickel austenitic stainless steels such as Type 304. They also offer higher creep, stress-rupture and tensile strength at elevated temperature. The nitrogen in Type 316LN adds additional resistance to sensitization in some circumstances.

The nitrogen content of Type 316LN stainless steel also provides some solid solution hardening, raising its minimum specified yield strength compared to Type 316L stainless steel. Like Types 316 and 316L, the Type 316LN alloy also offers good resistance to general corrosion and pitting/crevice corrosion.

Available tube product forms

TECHNICAL DATA

Mechanical Properties

Temper Annealed Cold worked
Tensile Rm 75 ksi (min) 125 ksi (min)
Tensile Rm 515 MPa (min) 860 MPa (min)
R.p. 0.2% Yield 30 ksi (min) 100 ksi (min)
R.p. 0.2% Yield 205 MPa (min) 690 MPa (min)
Elongation (2" or 4D gl) 35 % (min) 15 % (min)


Physical Properties (Room Temperature)

Specific Heat (0-100°C) 485 J.kg-1.°K-1
Thermal Conductivity 16.3 W.m -1.°K-1
Thermal Expansion 16.5 mm/m/°C
Modulus Elasticity 200 GPa
Electrical Resistivity 7.4 μohm/cm
Density 7.99 g/cm3







Chemical Composition (% by weight)

Element Min Max
C - 0.03
Mn - 2
Ni 13 15
Cr 17 19
Mo 2 3
S - 0.1
Si - 0.75
P - 0.25

ASTM A240 / A240M AISI 316LN DIN 1.4429 Stainless Steel Sheets And Plates 2B And NO.1 Finish 0ASTM A240 / A240M AISI 316LN DIN 1.4429 Stainless Steel Sheets And Plates 2B And NO.1 Finish 1
