Product Details:
Place of Origin: China
Brand Name: MITTEL STEEL
Certification: SGS ISO MTC
Model Number: C276
Payment & Shipping Terms:
Minimum Order Quantity: 5KGS
Price: 50 USD/KG
Packaging Details: Export Packing
Delivery Time: 7 Days
Payment Terms: L/C, T/T
Supply Ability: 50000KGS

C-276 N10276 Hastelloy Pipe Hastelloy C276 Astm 494 Hastelloy C-276 Seamless Pipe Hastelloy C-276 Welded Pipe

Description
Type: Nickel Pipe, Seamless/SML Grade: Hastelloy
O.D: 6-60.3mm W.T: 0.71-5mm
Technique: Cold Finished (Cold Drawing Surface Treatment: Pickled,Passivation,Inside & Outsid
High Light:

seamless stainless steel tube

,

astm stainless steel pipe

Hastelloy C 276 N10276 Cold Finished Seamless Stainless Hastelloy Tube

Name Hastelloy C 276 N10276 Cold Finished Seamless Stainless Hastelloy Tube
Standard ASTM B163/ASME SB163,ASTM B165/ASME SB165,ASTM B167/ASME SB167,
ASTM B704/ASME SB704,ASTM B705/ASME SB705,etc.
Material C276,UNS N10276,C22, UNS N06022, Hastelloy C-4,Hastelloy X, Hastelloy B,Hastelloy B-3, etc.
Type Seamless/SML
O.D 6-60.3mm
W.T 0.71-5mm
Length 1000-38000mm
Technique Cold Finished (Cold Drawing and Cold Rolling), Hot Finished (Hot Extrusion)
Ends PE/Plain Ends, BE/Beveled Ends
Surface Treatment Pickled,Passivation,Inside & Outside Mechanical Polishing, BA, Electropolishing (EP)
Heat Treatment Condition Solution Annealing and water rapid quenched, Bright Annealing
Test Requirement Eddy Current Test, Hydrostatic Test, UT,Penetrant Test,Air underwater pressure Test,
PMI Test, Spectro Test,Intergranular Corrosion Test,Sharpy Impact Test,Hardness Test,
Tension Test (Elongation,Yield Strength,Tensile Strength),Flarring Test etc.
Application Heat Exchanger,Boiler,Gas and Fluid Transportation;Mechanical Pipline;Engineering Projects;Petrochemical industry;Power Station
Certificate ISO9001:2008,PED/97/23/EC and China Pressure Vessel Pipeline Manufacturing License(A1 & A2)
Capacity 3000 tons/year
Package In bundles, plywood cases, wooden cases with water-proof package, etc.
Product Origin Jiangsu, China(mainland).
Payment Terms T/T, L/C
Nearest Port Shanghai,
Main Market Domestic Market, North America, Western Europe, South America, Eastern Asia etc.




Hastelloy C276 is a nickel-molybdenum-chromium superalloy with an addition of tungsten designed to have excellent corrosion resistance in a wide range of severe environments. The high nickel and molybdenum contents make the nickel steel alloy especially resistant to pitting and crevice corrosion in reducing environments while chromium conveys resistance to oxidizing media. The low carbon content minimizes carbide precipitation during welding to maintain corrosion resistance in as-welded structures. This nickel alloy is resistant to the formation of grain boundary precipitates in the weld heat-affected zone, thus making it suitable for most chemical process application in an as welded condition.

Although there are several variations of the Hastelloy nickel alloy, Hastelloy C-276 is by far the most widely used.

Alloy C-276 is widely used in the most severe environments such as chemical processing, pollution control, pulp and paper production, industrial and municipal waste treatment, and recovery of sour natural gas.

In what forms is Hastelloy C276 Available at Mega Mex?

  • Bar
  • Sheet
  • Plate
  • Pipe & Tube (welded and seamless)
  • Pipe Fittings
  • Welding Wire

Corrosion Resistant Hastelloy C276

Considered one of the most versatile corrosion resistant alloys available, Hastelloy C-276 exhibits excellent resistance in a wide variety of chemical process environments including those with ferric and cupric chlorides, hot contaminated organic and inorganic media, chlorine, formic and acetic acids, acetic anhydride, seawater, brine and hypochlorite and chlorine dioxide solutions. In addition, alloy C-276 resists formation of grain boundary precipitates in the weld heat affected zone making it useful for most chemical processes in the as-welded condition. This alloy has excellent resistance to pitting and stress corrosion cracking.

What are the characteristics of Hastelloy C276?

  • Excellent corrosion resistance in reducing environments
  • Exceptional resistance to strong solutions of oxidizing salts, such as ferric and cupric chlorides
  • High nickel and molybdenum contents providing good corrosion resistance in reducing environments
  • Low carbon content which minimizes grain-boundary carbide precipitation during welding to maintain resistance to corrosion in heat-affected zones of welded joints
  • Resistance to localized corrosion such as pitting and stress-corrosion cracking
  • One of few materials to withstand the corrosive effects of wet chlorine gas, hypochlorite and chlorine dioxide

Chemical Composition, %

Ni
Mo Cr Fe W Co Mn C
Remainder
15.0-17.0 14.5-16.5 4.0-7.0 3.0-4.5 2.5 max 1.0 max .01 max
V
P S Si
.35 max
.04 max .03 max .08 max

Hastelloy Applications

Hastelloy serves many different applications in these industry categories:

  • Chemical Process
  • Petrochemical
  • Oil & Gas
  • Pharmaceutical
  • Geothermal
  • Sea Water
  • Water Desalination
  • LNG (Liquefied Natural Gas)
  • Biomass
  • Mining
  • Utilities
  • Nuclear Power
  • Solar Power
