Product Details:
|
| Width: | 1000-3500mm | Length: | 2000-12000mm |
|---|---|---|---|
| Surface: | Black | Type: | Plate And Coil |
| Condition: | Hot Rolled | Supplementary Technology: | HIC Test |
| High Light: | high strength steel plate,hot rolled steel plate |
||
ASME SA515 standard specification for pressure vessel plates, carbon steel, for intermediate-and higher-temperature service
ASME SA515 grade 70 plates shall be normalized.
Supplementary Technology: HIC Test | NACE MR0175 | Z15 | Z25 | Z35 | S1 | S2 | S3 | S4.1
S5 | S6 | S7 | S8 | S9| S11 | S12 | S17
Thickness: 6MM to 300MM,
Width: 1500mm to 4050mm,
Length: 3000mm to 15000mm
Gangsteel is specialized in supplying ASME SA515 steel plate in SA515 grade 70. For more information of SA515 grade 70 steel plates, please check them in following:
| SA515 grade 70 Chemical Composition | |||||
| Grade | The Element Max (%) | ||||
| C | Mn | P | S | Si | |
| SA515 grade 70 | 0.30-0.35 | 1.30 | 0.035 | 0.035 | 0.13-0.45 |
Carbon Equivalent: Ceq = 【C+Mn/6+(Cr+Mo+V)/5+(Ni+Cu)/15】%
| Grade | SA515 grade 70 Mechanical Property | |||
| Thickness | Yield | Tensile | Elongation | |
| SA515 grade 70 | mm | Min Mpa | Mpa | Min % |
| 200 | 260 | 485-620 | 17 | |
| 50 | 21 | |||
Shipbuilding steel plate| Alloy steel plates| High strength plate| Carbon steel plate| Stainless steel plate
| Equivalent steel grade of SA515 grade 70 | |||||||
| Europe | Belgium | Germany | France | Italy | Sweden | UK | Japan |
| KG,KW,KT | W St E 315 | A48 CP,AP,FP | Fe 460-2-KW | SS21,02,01 | Gr 360,400 | ||
If you need more stock steel plates in pressure vessel steel plate, please click warehouse sizes.
Main application of ASME SA515 Grade 70 are used to build boilers and pressure vessels such as petroleum, chemical industry, power plants.
Additional technical services for SA515 Gr.70 boiler steel plate from MITTEL which including Heat treatment(Normalized,TMCP,Quenched and Tempered,N+T),Z-test (Z15,Z25,Z35),Ultrasonic Examination,Low temperature impacting test,DWTT,PWHT and cutting&welding into special pieces for end users. Mill test certificate issued under EN 10204 format.
our advantage of supplying SA515/SA515M SA515 Grade 70 Pressure vessel steel plate I.Professional in steel knowledge for guanrantee steel property. II. Widest steel resources for accepting customers’ small orders. III. Closest relationships with china national mills for guanrantee delivery time and even delivery in advance.
